Sharp LC-45GD5U User Manual

LC-45GD5U
ERSATZTEILLISTE
AUSTAUSCH VON TEILEN
Les pi`eces de rechange qui pr élelesentent ces caract éleristiques
sp éleciales de s élecurit éle, sont identifi élees dans ce manuel :
lespi`eces élelectriques qui pr élesentent ces particularit éles, sont
rep éler élee par la marque ået sont hachur élees dans les listes de
pi`eces et dans les diagrammes sch élematiques.
La substitution d'une pi`ece de rechange par une autre qui ne pr
éLesente pas les m éoemes caract éLeristiques de s élecurit éle
que la pi`ece recommand élee parl'usine et dans ce manuel de serv-
ice, peut provoquer une éLelectrocution, un incendie ou toutautre
sinistre.
"COMMENT COMMANDER LES PIECES DE RECHANGE"
Pour que votre commande soit rapidement et correctement remplie,
veuillez fournir les renseignements suivants.
1. NUMERO DU MODELE 2. NO. DE REF
3. NO. DE PIECE 4. DESCRIPTION
in CANADA: Contact SHARP Electronics of Canada Limited
Phone (416) 890-2100
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
are identified by å and shaded areas in the Replacement Parts
Lists and Schematic Diagrams. The use of a substitute replacement
part which dose no have the same safety characteristic as the fac-
tory recommended replacement parts shown in this service manual
may create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
in USA: Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor, Please call Toll-
Free; 1-800-BE-SHARP
★ MARKIERUNG : ERSATZTEILE-LIEFERUNG★ MARK: SPARE PARTS-DELIVERY SECTION
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
106
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
DUNTKD154VJ03 – AC INPUT Unit —
DKEYDD392VJ12 – DIGITAL TUNER Unit —
DUNTKD393VJ03 – MAIN Unit —
DUNTKD405UJ02 – AV Unit —
DUNTKD406UJ02 – KEY Unit —
DUNTKD407UJ02 – R/C, LED Unit —
DUNTKD408UJ02 – SPEAKER TERMINAL-L Unit—
DUNTKD409UJ02 – SPEAKER TERMINAL-R Unit —
DUNTKD410UJ02 – BUS CONNECT Unit —
RDENCA142WJQZ – POWER SUPPLY Unit —
DIODES
åVA7801 RH-VXA018WJN1 J Varistor AD
åVA7802 RH-VXA018WJN1 J Varistor AD
TRANSFORMERS
åT7801 RCiLFA132WJZZ J Coil AG
åT7802 RCiLFA132WJZZ J Coil AG
CAPACITORS
åC7801 RC-FZ029SCEZZ J 0.22 275V AD
åC7802 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
åC7803 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
åC7804 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
åC7805 RC-KZ0091GEZZ J 2200p 250V Ceramic AC
åC7806 RC-FZ029SCEZZ J 0.22 275V AD
RESISTORS
åR7801 RR-HZA011WJN1 J 560k 1W AC
åR7802 RR-HZ0008GEN1 J 3.9M 1W AC
å R7803 RR-HZ0008GEN1 J 3.9M 1W AC
MISCELLANEOUS PARTS
åF7801 QFS-DA013WJZZ J Fuse,250V AF
FH7801 QFSHD1002CEZZ J Fuse Holder AA
FH7803 QFSHD1002CEZZ J Fuse Holder AA
åP7801 QSOCAA001WJZZ J Socket,3PiN AL
P7802 QPLGN0269GEZZ J Plug,2PiN(AC) AB
åSG7801 QSPGCA003WJZZ J Spark Gap AH
LUG7801 QLUGHA002WJZZ J Lug AB
LUG7802 QLUGHA002WJZZ J Lug AB
LUG7803 QLUGHA002WJZZ J Lug AB
LUG7804 QLUGHA002WJZZ J Lug AB
LANGQA013WJFW J Fixing Metal AH
LHLDWA055WJKZ J Holder AC
XBPS730P08JS0 J Screw AB
XBSS830P08000 J Screw AA
DUNTKD154VJ03
AC INPUT Unit

Sharp LC-45GD5U Specifications

General

Brand	Sharp
Model	LC-45GD5U
Category	LCD TV
Language	English
