Part names
POWER indicator
OPC sensor
TV (Front)
POWER button
INPUT button*
Volume buttons (VOL +/ - )
Channel
buttons**
(CH /)
Remote
control sensor
*OPC: Optical Picture Control
*DL: DownLoad
OPC indicator
* INPUT button works as
ENTER in TV Guide On
Screen
** Channel buttons work as
'/" in TV Guide On
Screen
NOTE
• For status indicator .
DL indicator
SLEEP indicator
Headphone jack
(When connecting
headphones, the sound
from the speakers is
muted.)
Part names
TV (Rear)
* Press RESET if the TV cannot return to its original state after performing various operations.
•AV MODE resets to DYNAMIC (Fixed)
• TV channel returns to initial channel (Air:2ch, Cable:1 or 2ch)
• Audio setting initializes
• Dolby Virtual resets to off
•Image position initializes
** Press SYSTEM RESET if the TV does not operate after starting up.
NOTE
•Pressing RESET will not work if the TV is in standby mode.
•Pressing RESET will not delete channel preset or secret number. For clearing the secret number when you
know it. For initializing to the factory preset values when you forget your secret number.
INPUT 2
terminals
MONITOR OUT/
REC OUT terminals
i.LINK terminals
CableCARD™ slot
G-LINK terminal
DIGITAL AIR
IN terminal
RESET*
INPUT 3
terminals
SYSTEM
RESET**
ANALOG IN
terminal
AC INPUT terminal
RS-232C terminal
INPUT 1
terminals
INPUT 5 terminals
INPUT 4 terminal
DIGITAL AUDIO
OUTPUT terminal
DIGITAL
CABLE IN
terminal
