Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
LC-45GD5U
133
DUNTKD406UJ02
KEY Unit
TRANSISTORS
Q2451 VSDTC314TK/-1Y J DTC314TK AC
DIODES
D2451 RH-EXA092WJZZY J Zener Diode, 12V AB
D2455 RH-EXA092WJZZY J Zener Diode, 12V AB
RESISTORS
R2451 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R2452 VRS-CY1JF123JY J 12k 1/16W Metal Oxide AA
R2453 VRS-CY1JF822JY J 8.2k 1/16W Metal Oxide AA
R2454 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
SWITCHES
S2451 QSW-K0108CEZZY J Switch, CH-UP AD
S2452 QSW-K0108CEZZY J Switch, CH-DOWN AD
S2453 QSW-K0108CEZZY J Switch, INPUT AD
S2454 QSW-K0108CEZZY J Switch, VOL-UP AD
S2455 QSW-K0108CEZZY J Switch, VOL-DOWN AD
S2457 QSW-K0108CEZZY J Switch AD
MISCELLANEOUS PARTS
P2451 QPLGNA325WJZZY J Plug, 5Pin (KM) AC
TO LCD CONTROL
QCNW-D872WJQZ J Connecting Cord
INTEGRATED CIRCUITS
IC2401 VHiTPS850++-1Y J TPS850 AG
TRANSISTORS
Q2402 VS2SC2712Y/-1Y J 2SC2712Y AB
Q2403 VS2SC2712Y/-1Y J 2SC2712Y AB
Q2404 VS2SC3928AR-1Y J 2SC3928AR AB
Q2405 VS2SC3928AR-1Y J 2SC3928AR AB
Q2407 VS2SC3928AR-1Y J 2SC3928AR AB
Q2408 VS2SC3928AR-1Y J 2SC3928AR AB
Q2409 VSUM5K1NTR+-1Y J UM5K1NTR+ AC
DIODES AND LED'S
D2401 RH-EXA092WJZZY J Zener Diode, 12V AB
D2403 RH-PXA087WJZZY J PhotoDiode AG
D2413 RH-PXA089WJZZY J PhotoDiode AC
D2414 RH-PXA086WJZZY J PhotoDiode AC
D2415 RH-PXA086WJZZY J PhotoDiode AC
CAPACITORS
C2401 VCERMZ1CN107MY J 100 16V AD
C2402 VCKYTV1CF225ZY J 2.2 16V Ceramic AB
C2404 VCERML1CN106MY J 10 16V AC
C2405 VCKYCY1HF103ZY J 0.01 50V Ceramic AA
RESISTORS
R2401 VRS-CY1JF101JY J 100 1/16W Metal Oxide AA
R2402 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2404 VRS-CY1JF273JY J 27k 1/16W Metal Oxide AA
R2405 VRS-CY1JF393JY J 39k 1/16W Metal Oxide AA
R2406 VRS-CY1JF683JY J 68k 1/16W Metal Oxide AA
R2408 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R2409 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R2411 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R2412 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2413 VRS-TW2ED220JY J 22 1/4W Metal Oxide AB
R2414 VRS-CY1JF104JY J 100k 1/16W Metal Oxide AA
R2415 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R2417 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R2418 VRS-CY1JF221JY J 220 1/16W Metal Oxide AA
R2419 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R2422 VRS-CY1JF122JY J 1.2k 1/16W Metal Oxide AA
R2424 VRS-CJ1JF103JY J 10k 1/16W Metal Oxide AA
R2425 VRS-CY1JF223JY J 22k 1/16W Metal Oxide AA
R2426 VRS-CY1JF333JY J 33k 1/16W Metal Oxide AA
R2428 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R2429 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
MISCELLANEOUS PARTS
J2401 QJAKJA014WJZZ J Jack, 7Pin AD
P2401 QPLGNA335WJZZY J Plug, 15Pin TO AV3 AD
RMC2401 RRMCUA037WJZZ J Remote Receiver AF
SLD2401 PSLDM4646CEFW J Shield AD
QCNW-E001WJQZ J Connecting Cord
DUNTKD407UJ02
R/C, LED Unit
