Using external equipment
Connecting HDMI equipment
Please use the INPUT 4 terminal when connecting HDMI equipment.
Displaying an image from HDMI equipment
To watch an HDMI equipment image, select
“INPUT4” from “INPUT SOURCE” menu
using INPUT on the remote control unit or
on the Display.
INPUT SOURCE
TV
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5INPUT5
CARD
i.LINK
1
Press MENU and the MENU screen displays.
2
3
Press
'
/
"
to select “HDMI Setup”, and then
press ENTER.
4
Press
\
/
|
to select “Option”.
MENU
[
Option
...
HDMI Setup
]
Option
3D Noise Reduction
Mosquito Noise Reduction
HDMI Setup
[Off]
[Low]
5
Press
'
/
"
to select the desired item and
press ENTER.
Press
'
/
"
/
\
/
|
to select the desired setting
and press ENTER.
6
NOTE
•Refer to your external equipment operation manual for
the signal type.
Selectable items
Auto/RGB/YCbCr
4:4:4/YCbCr 4:2:2
Auto/ITU601/
ITU709
Standard/
Out of standard
Enable/Disable
HDMI Setup
items
Signal
Type
Color
Matrix
Dynamic
Range
Auto View
Description
Select the signal type from
an HDMI terminal. Unless
the image quality looks
obviously poor, select Auto.
Select the internal color
space conversion method
when an RGB signal is
input. Normally, select
Auto.
Select the signal amplitude
range. Normally, select
Standard.
Set whether or not to use
VIEW MODE based on
signal recognition,
including an HDMI signal.
HDMI equipment
HDMI cable
(Commercially available)
AVC System (rear view)
Using external equipment
AVC System (rear view)
ø 3.5 mm stereo minijack cable
(commercially available)
PC with analog RGB terminal
Connecting a PC
Use the INPUT 5 terminal to connect a PC.
NOTE
• Refer to page for a list of PC signals compatible with the System.
ø 3.5 mm stereo minijack cable
(commercially available)
DVI cable
(Commercially available)
RGB/DVI conversion cable
(Commercially available)
PC with DVI terminal
To Next Page
