LC-46DH65E/S, LC-46DH66E
2 – 6
6. Removing of Panel Support Angles and LCD Panel Module
1. Remove the 16 lock screws and detach the Panel Support Angle.
2. Remove the 10lock screws and detach the LCD Panel Module.
1
Panel Support Angle
46" LCD Panel Module
2
2
1
