LC-46DH65E/S, LC-46DH66E
2 – 5
5. Removing of MAIN Unit, POWER Unit and Power PWB Holder
1. Remove the 8 lock screws and detach the MAIN Unit.
2. Remove the 6 lock screws and detach the POWER Unit Ass’y.
1
2
MAIN Unit
POWER Unit
POWER Unit Holder
