Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
6 – 30
• Does not sound.
No audio (1)
INPUT-6 No audio. INPUT-7 No audio. INPUT-5 No audio.
Is INPUT-6 selected on the input select
menu screen?
Is INPUT-7 selected on the input select
menu screen?
Is INPUT-5 selected on the input select
menu screen?
YES
NO
YES
NO
YES
NO
Refer to “: No external input
video [INPUT-6]”.
Refer to “: No external input
video [INPUT-7]”.
Refer to “: No external input
video [INPUT-5]”.
Is the audio output selected for “VARI-
ABLE” on the menu screen?
Is the audio output selected for “VARI-
ABLE” on the menu screen?
Is the audio output selected for “VARI-
ABLE” on the menu screen?
YES
NO
YES
NO
YES
NO
Set the audio output to
“FIXED”.
Set the audio output to
“FIXED”.
Set the audio output to
“FIXED”.
Does the audio signal come from pins (8)
(L) and (7) (R) of input terminal (J510) to
pins (AP34) (L) and (AU36) (R) of IC3301
(CPU)?
Does the audio signal come from pins (3)
(L) and (2) (R) of input terminal (J510) to
pins (AR37) (L) and (AT36) (R) of IC3301
(CPU)?
Does the audio signal come from pins (13)
(L) and (12) (R) of input terminal (J510) to
pins (AT37) (L) and (AT35) (R) of IC3301
(CPU)?
YES
NO
YES
NO
YES
NO
Check the line between J510
and IC3301.
Check the line between J510
and IC3301.
Check the line between J510
and IC3301.
Does the digital audio signal come from pins(AR11/AP11/AN9)(CPU_AOBCK/AOLRCK/AOSDATA0) of IC3301(CPU) to pins(8/9/7)(SP_BCLK/
SP_LRCLK/SP_DATA) of IC1702(Audio DSP)?
YES
NO
Check the line between IC3301 and IC1702, and their paripheral circuits.
• About the L/R Speakers.
Does the digital audio signal come from pins (27/29/32/34) of IC1702 (Audio DSP) to pin (4/3/2/1) of IC1903 (connector for L/R)?
• About the Subwoofer speaker.
Does the digital audio signal come from pins (43/44/46/48) of IC1702 (Audio DSP) to pin (7/8/6/5) of IC1705 (AMP for SW)?
YES
NO
Check IC2702 and its paripheral circuits.(X1701, etc.)
• About the L/R Speakers.
Check the connector (P1903) L/R speakers and their peripheral circuits.
• About the Subwoofer Speaker.
Is the audio output from IC1705 as specified?
YES
NO
• About the Subwoofer Speaker.
Check IC1705 and its peripheral circuits.
• About the Subwoofer Speaker.
Check the connector (P1904), subwoofer speaker and their peripheral circuits.

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
