[4] Precautions for assembly (LC-60/70EQ10U/SQ10U,15U,17U)
1. Points to be checked and precautions when servicing the unit
Mount the main PWB Ass’y on the backlight chassis and check that the EMI-prevention parts are not peeled and twisted from the access holes. (The
EMI-prevention parts, conductive nonwoven fabric gaskets, must be seen from the access holes.)
[Countermeasure]
Attach the conductive nonwoven fabric gaskets on the shielded case on the main PWB.
• LC-60EQ10U/SQ10U,15U,17U
Back side
(1) Prepare ***
LAN GKD145WJFW
TE RM ANG SIDE
(2) Stick ***
PSPA Z C6 90WJZ Z
CONDUCTR:8x 255
Positioni ng
Posit io ning
Back side
Positioning
Pos itionin g
(1) Prepare ***
LAN GKD146WJFW
TE RM ANG BOTTOM
(2) Stick ***
PSPA ZC691 WJZZ
CONDUCTR:8x180
