Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
iv
LC-60EQ10U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
• LC-60/70EQ10U
• LC-60/70SQ10U
• LC-60/70SQ15U
• LC-60/70SQ17U
• LC-60/70TQ15U
NO. PARTS CODE DESCRIPTION
N DKEYMG381FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60EQ10U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70EQ10U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM02 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60EQ10U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70EQ10U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ10U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ10U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM02 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ10U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ10U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ15U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ15U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ15U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ15U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM01 LCD CONTROL (T-CON) Unit (LC-60SQ17U)
N DUNTKG400FM02 LCD CONTROL (T-CON) Unit (LC-70SQ17U)
N DUNTKF800FM53 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJQZ WiFi+BT Unit
N RUNTKB109WJQZ POWER/DRIVE Unit (LC-60SQ17U)
N RUNTKB131WJQZ POWER/DRIVE Unit (LC-70SQ17U)
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM10 LCD CONTROL (T-CON) Unit (LC-60TQ15U)
N DUNTKG400FM11 LCD CONTROL (T-CON) Unit (LC-70TQ15U)
N DUNTKF800FM54 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJN1 WiFi+BT Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60TQ15U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70TQ15U)
N RUNTKB075WJZZ LED Unit (LC-60TQ15U)
N RUNTKB077WJZZ LED Unit (LC-70TQ15U)

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
