Sharp LC-60EQ10U Service Manual

PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70EQ10U)
[2] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70SQ10U)
[3] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70SQ15U)
[4] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70SQ17U)
[5] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70TQ15U)
[6] PRINTED WIRING BOARD
ASSEMBLIES (LC-60/70UQ17U)
[7] LCD PANEL MODULE UNIT
[8] CABINET AND MECHANICAL
PARTS (LC-60EQ10U)
[9] CABINET AND MECHANICAL
PARTS (LC-70EQ10U)
[10] CABINET AND MECHANICAL
PARTS (LC-60SQ10U)
CONTENTS
No. S14A1LC60EQ10
LC-60/70EQ10U
LC-60/70SQ10U
LC-60/70SQ15U
LC-60/70SQ17U
LC-60/70TQ15U
LC-60/70UQ17U
LCD COLOR TELEVISION
MODELS

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
