Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
3
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70EQ10U)
N DKEYMG381FM01 BV X MAIN Unit
N DUNTKG400FM01 BN N X LCD CONTROL (T-CON) Unit (LC-60EQ10U)
N DUNTKG400FM02 BN N X LCD CONTROL (T-CON) Unit (LC-70EQ10U)
N DUNTKF800FM53 AE X KEY Unit
N DUNTKG369FM02 AG N X RC/ICON Unit
N RUNTKB222WJQZ AZ N X WiFi+BT Unit
!
N RUNTKB109WJQZ BG X POWER/DRIVE Unit (LC-60EQ10U)
!
N RUNTKB131WJQZ BK X POWER/DRIVE Unit (LC-70EQ10U)
[2] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70SQ10U)
N DKEYMG382FM01 BW N X MAIN Unit
N DUNTKG400FM01 BN N X LCD CONTROL (T-CON) Unit (LC-60SQ10U)
N DUNTKG400FM02 BN N X LCD CONTROL (T-CON) Unit (LC-70SQ10U)
N DUNTKF800FM53 AE X KEY Unit
N DUNTKG369FM02 AG X RC/ICON Unit
N RUNTKB222WJQZ AZ N X WiFi+BT Unit
!
N RUNTKB109WJQZ BG X POWER/DRIVE Unit (LC-60SQ10U)
!
N RUNTKB131WJQZ BK X POWER/DRIVE Unit (LC-70SQ10U)
[3] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70SQ15U)
N DKEYMG382FM01 BW N X MAIN Unit
N DUNTKG400FM01 BN N X LCD CONTROL (T-CON) Unit (LC-60SQ15U)
N DUNTKG400FM02 BN N X LCD CONTROL (T-CON) Unit (LC-70SQ15U)
N DUNTKF800FM53 AE X KEY Unit
N DUNTKG369FM01 AG X RC/ICON Unit
N RUNTKB222WJQZ AZ N X WiFi+BT Unit
!
N RUNTKB109WJQZ BG X POWER/DRIVE Unit (LC-60SQ15U)
!
N RUNTKB131WJQZ BK X POWER/DRIVE Unit (LC-70SQ15U)
[4] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70SQ17U)
N DKEYMG382FM01 BW N X MAIN Unit
N DUNTKG400FM01 BN N X LCD CONTROL (T-CON) Unit (LC-60SQ17U)
N DUNTKG400FM02 BN N X LCD CONTROL (T-CON) Unit (LC-70SQ17U)
N DUNTKF800FM53 AE X KEY Unit
N DUNTKG369FM01 AG X RC/ICON Unit
N RUNTKB222WJQZ AZ N X WiFi+BT Unit
!
N RUNTKB109WJQZ BG X POWER/DRIVE Unit (LC-60SQ17U)
!
N RUNTKB131WJQZ BK X POWER/DRIVE Unit (LC-70SQ17U)
[5] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70TQ15U)
N DKEYMG382FM01 BW N X MAIN Unit
N DUNTKG400FM10 N X LCD CONTROL (T-CON) Unit (LC-60TQ15U)
N DUNTKG400FM11 N X LCD CONTROL (T-CON) Unit (LC-70TQ15U)
N DUNTKF800FM54 AE N X KEY Unit
N DUNTKG369FM01 AG N X RC/ICON Unit
N RUNTKB222WJN1 N X WiFi+BT Unit
!
N RUNTKB116WJQZ BK N X POWER/DRIVE Unit (LC-60TQ15U)
!
N RUNTKB118WJQZ BM N X POWER/DRIVE Unit (LC-70TQ15U)
N RUNTKB075WJZZ AZ N X LED Unit (LC-60TQ15U)
N RUNTKB077WJZZ AY N X LED Unit (LC-70TQ15U)
[6] PRINTED WIRING BOARD ASSEMBLIES (LC-60/70UQ17U)
N DKEYMG382FM01 BW N X MAIN Unit
N DUNTKG400FM10 N X LCD CONTROL (T-CON) Unit (LC-60UQ17U)
N DUNTKG400FM11 N X LCD CONTROL (T-CON) Unit (LC-70UQ17U)
N DUNTKF800FM54 AE N X KEY Unit
N DUNTKG369FM01 AG N X RC/ICON Unit
N RUNTKB222WJN1 N X WiFi+BT Unit
!
N RUNTKB116WJQZ BK N X POWER/DRIVE Unit (LC-60UQ17U)
!
N RUNTKB118WJQZ BM N X POWER/DRIVE Unit (LC-70UQ17U)
N RUNTKB075WJZZ AZ N X LED Unit (LC-60UQ17U)
N RUNTKB077WJZZ AY N X LED Unit (LC-70UQ17U)
[7] LCD PANEL MODULE UNIT
N R1JE601D3GW00Z EG N X 60" LCD PANEL MODULE Unit (LC-60EQ10U) (JE601D3GW00Z)
N R1JE695D3GV10Z EH N X 70" LCD PANEL MODULE Unit (LC-70EQ10U) (JE695D3GV10Z)
N R1JE601D3GW00Z EG N X 60" LCD PANEL MODULE Unit (LC-60SQ10U) (JE601D3GW00Z)
N R1JE695D3GV10Z EH N X 70" LCD PANEL MODULE Unit (LC-70SQ10U) (JE695D3GV10Z)
N R1JE601D3GW00Z EG N X 60" LCD PANEL MODULE Unit (LC-60SQ15U) (JE601D3GW00Z)
N R1JE695D3GV10Z EH N X 70" LCD PANEL MODULE Unit (LC-70SQ15U) (JE695D3GV10Z)
N R1JE601D3GW00Z EG N X 60" LCD PANEL MODULE Unit (LC-60SQ17U) (JE601D3GW00Z)
N R1JE695D3GV10Z EH N X 70" LCD PANEL MODULE Unit (LC-70SQ17U) (JE695D3GV10Z)

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
