Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
2
[11] CABINET AND MECHANICAL
PARTS (LC-70SQ10U)
[12] CABINET AND MECHANICAL
PARTS (LC-60SQ15U)
[13] CABINET AND MECHANICAL
PARTS (LC-70SQ15U)
[14] CABINET AND MECHANICAL
PARTS (LC-60SQ17U)
[15] CABINET AND MECHANICAL
PARTS (LC-70SQ17U)
[16] CABINET AND MECHANICAL
PARTS-1 (LC-60TQ15U)
[17] CABINET AND MECHANICAL
PARTS-2 (LC-60TQ15U)
[18] CABINET AND MECHANICAL
PARTS-1 (LC-70TQ15U)
[19] CABINET AND MECHANICAL
PARTS-2 (LC-70TQ15U)
[20] CABINET AND MECHANICAL
PARTS-1 (LC-60UQ17U)
[21] CABINET AND MECHANICAL
PARTS-2 (LC-60UQ17U)
[22] CABINET AND MECHANICAL
PARTS-1 (LC-70UQ17U)
[23] CABINET AND MECHANICAL
PARTS-2 (LC-70UQ17U)
[24] SUPPLIED ACCESSORIES/
PACKING PARTS
(LC-60EQ10U,SQ10U/15U/17U)
(NOT REPLACEMENT ITEM)
[25] SUPPLIED ACCESSORIES/
PACKING PARTS
(LC-70EQ10U,SQ10U/15U/17U)
(NOT REPLACEMENT ITEM)
[26] SUPPLIED ACCESSORIES/
PACKING PARTS (LC-60TQ15U)
(NOT REPLACEMENT ITEM)
[27] SUPPLIED ACCESSORIES/
PACKING PARTS (LC-70TQ15U)
(NOT REPLACEMENT ITEM)
[28] SUPPLIED ACCESSORIES/
PACKING PARTS (LC-60UQ17U)
(NOT REPLACEMENT ITEM)
[29] SUPPLIED ACCESSORIES/
PACKING PARTS (LC-70UQ17U)
(NOT REPLACEMENT ITEM)
[30] SERVICE JIG
(USE FOR SERVICING)
(LC-60/70EQ10U/SQ10U,15U,17U)
[31] SERVICE JIG
(USE FOR SERVICING)
(LC-60/70TQ15U/UQ17U)

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
