Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
47
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[29] SUPPLIED ACCESSORIES/PACKING PARTS (LC-70UQ17U) (NOT REPLACEMENT ITEM)
X1 CDAi-A919WJ03 N X Stand Base Ass'y
X2 CANGKE168WJ31 N X Stand Support Ass'y
X3 CSAKKA023WJ31 N X Stand Screw Ass'y
X4 TCADEA290WJZZ AA X Enquete Card
X5 TiNS-G058WJZZ AD N X SET UP Guide
X6 RRMCGB118WJSA AN N X Remote Control Unit
X7 Not Available - - AAA Size Battery, x2
X8 KOPTLA006WJN1 BN N X 3D Glasses (LC-70UQ17U)
S1 SPAKAA724WJZZ - - Edge Board (Top) (NOT REPLACEMENT ITEM)
S2 SPAKAA725WJZZ - - Edge Board (Bottom) (NOT REPLACEMENT ITEM)
S3 SPAKCH469WJZZ - N - Packing Case (NOT REPLACEMENT ITEM)
S4 SPAKCH473WJZZ - N - Packing Case (Bottom) (NOT REPLACEMENT ITEM)
S5 SPAKPB733WJZZ - - Polyethylene Bag (Main) (NOT REPLACEMENT ITEM)
S6 SPAKXE214WJZZ - N - Packing Form (Top) (NOT REPLACEMENT ITEM)
S7 SPAKXE215WJZZ - N - Packing Form (Bottom) (NOT REPLACEMENT ITEM)
S8 SSAKA0101GJZZ - - Polyethylene Bag (NOT REPLACEMENT ITEM)
S9 TLABKA009WJZZ - - Case No. Label (NOT REPLACEMENT ITEM)
[30] SERVICE JIG (USE FOR SERVICING) (LC-60/70EQ10U/SQ10U,15U,17U)
N QCNW-C222WJQZ AW J Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ AV J
Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2 (LC-60/
70EQ10U)
N QCNW-F676WJQZ BH J Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ BC J
Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit
(PL)
[31] SERVICE JIG (USE FOR SERVICING) (LC-60/70TQ15U/UQ17U)
N QCNW-C222WJQZ AW J Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ AV J Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-N560WJQZ AW J Connecting Cord L=650mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ BC J
Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit
(PL)

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
