Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
v
• LC-60/70UQ17U
NOTE: *1 Replace MAIN PWB Units (DKEYMG381FM01) in case of IC3103 failure.
Replace MAIN PWB Units (DKEYMG382FM01) in case of IC3103, IC3301 failure.
*2 Replace LCD CONTROL Units (DUNTKG400FM**) in case of IC5803 failure.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
NO. PARTS CODE DESCRIPTION
N DKEYMG382FM01 MAIN Unit
N DUNTKG400FM10 LCD CONTROL (T-CON) Unit (LC-60UQ17U)
N DUNTKG400FM11 LCD CONTROL (T-CON) Unit (LC-70UQ17U)
N DUNTKF800FM54 KEY Unit
N DUNTKG369FM01 RC/ICON Unit
N RUNTKB222WJN1 WiFi+BT Unit
N RUNTKB116WJQZ POWER/DRIVE Unit (LC-60UQ17U)
N RUNTKB118WJQZ POWER/DRIVE Unit (LC-70UQ17U)
N RUNTKB075WJZZ LED Unit (LC-60UQ17U)
N RUNTKB077WJZZ LED Unit (LC-70UQ17U)
Ref No. Parts No. Description Q’ty
IC2004 RH-iXD515WJNSQ IC (Monitor Microprocessor) 1
IC2503 RH-iXD741WJZZS IC (Flash for HDMI receiver) (DKEYMG382FM01) 1
NO. PARTS CODE DESCRIPTION
SERVICE JIG (USE FOR SERVICING) (LC-60/70EQ10U/SQ10U,15U,17U)
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2 (LC-60/70EQ10U)
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit (PL)
SERVICE JIG (USE FOR SERVICING) (LC-60/70TQ15U/UQ17U,80UQ17U)
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ Connecting Cord L=1000mm 64pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-N560WJQZ Connecting Cord L=650mm 41pins, Main to LCD Control Unit (LW)
N QCNW-M539WJQZ Connecting Cord L=1200mm 24-24-4pins, Main(PD) to Power(PD) to LCD Control Unit (PL)

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
