LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
5
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[8] CABINET AND MECHANICAL PARTS (LC-60EQ10U)
1 CCABAD080WJ34 BD N X Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 Not Available - - R/C LED Decoration
1-3 HDECSA115WJ3A AR X Shine Trim
1-4 TLABZE300WJSA X QUATTRON Label
1-5 LHLDWA175WJUZ AA X Wire Holder
1-6 LHLDWA289WJKZ AA X Wire Holder
1-7 TLABZD496WJZZ AA X Licence Label
2 CCABBC175WJ31 BE X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - N - Terminal Label (Side)
2-3 Not Available - N - Terminal Label (Bottom)
2-4 Not Available - - KEY Indication
2-5 PSPAHC682WJZZ AB N X Himeron
2-6 PSPAHC683WJZZ AB N X Himeron, x2
3 CANGKD823WJ31 AE X VESA Angle Ass'y, x4
3-1 Not Available - N - VESA Angle
3-2 Not Available - - VESA Shaft
4 TLABNB037WJZZ AB X Serial Label (Back)
5 Not Available - N - Serial Label (Side)
6 LANGKD145WJFW AD X Terminal Angle (Side)
7 LANGKD146WJFW AC X Terminal Angle (Bottom)
8 LANGKD821WJ3W AF X Stand Fix Angle, x2
9 NSFTZA459WJF7 AC J Tray Shaft, x6
10 PSPAZC690WJZZ AF J Gasket
11 PSPAZC691WJZZ AE J Gasket
12 PSPAZC805WJKZ AK J Cooler, x2
13 QCNW-N184WJZZ AD N X Connecting Cord (FFC 64Pin), x2
14 QCNW-N236WJZZ AR X Connecting Cord (LW)
15 QCNW-N675WJZZ AD X Connecting Cord (FFC 80Pin), x2
16 QCNW-N702WJZZ AL N X Connecting Cord (PD/PL)
17 RCORFA061WJZZ AG J Ferrite Core, x4
18 GCOVAE552WJ3A AE X Bottom Cover (L)
19 GCOVAE553WJ3A AE X Bottom Cover (R)
20 G
COV
AE555WJ3A AD X AC Cord Cover
21 HiNDPF019WJZZ AC X Energy Guide Label
22 HiNDPF076WJSA AC N X Model Label
23 JBTN-A985WJ3A AC N X KEY Button
24 LHLDWA318WJKZ AD J Cable Tie
25 LHLDZB989WJ3Z AC X WiFi Holder
26 QCNW-M030WJZZ AE X Connecting Cord (SP)
27 QCNW-N242WJZZ AH N X Connecting Cord (RA)
28 QCNW-N243WJZZ AH N X Connecting Cord (UB)
29 RSP-ZA615WJZZ AY J Speaker Unit (L)
30 RSP-ZA616WJZZ AY J Speaker Unit (R)
!
31 QACCDA084WJPZ AG X AC Cord
32 XBPS830P06WS0 AA X Screw, x19
33 LHLDWA175WJKZ AA X Wire Holder
34 LHLDWA124WJKZ AB X Wire Holder, x2
35 LHLDWA289WJKZ AA X Wire Holder
36 LHLDZB951WJKZ AB X Power Spacer, x2
37 LX-BZA207WJF7 AA X Screw, x48
38 XEBS830P12000 AA X Screw, x9
39 LX-EZA069WJF7 AA X Screw, x2
40 LX-BZA473WJN1 AB X Screw, x2
41 XEPS830P12WS0 AA X Screw, x3
