Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[9] CABINET AND MECHANICAL PARTS (LC-70EQ10U)
1 CCABAD081WJ34 BE N X Front Cabinet Ass'y
1-1 Not Available - N - Fronr Cabinet
1-2 Not Available - N - R/C LED Decoration
1-3 HDECSA116WJ3A AR N X Shine Trim
1-4 TLABZE300WJSA X QUATTRON Label
1-5 LHLDWA175WJUZ AA X Wire Holder, x2
1-6 TLABZD496WJZZ AA X Licence Label
2 CCABBC177WJ31 BK X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - - Terminal Label (Side)
2-3 Not Available - - Terminal Label (Bottom)
3 DCOVAE559WE01 AK X KEY Unit Ass'y
3-1 Not Available - N - KEY Button Cover
3-2 JBTN-A937WJ3A AZ J KEY Button
3-3 XEBS830P08000 AA J Screw, x2
4 CANGKD824WJ31 AE N X VESA Angle Ass'y, x4
4-1 Not Available - N - VESA Angle
4-2 Not Available - - VESA Shaft
5 TLABNB037WJZZ AB X Serial Label (Back)
6 Not Available - N - Serial Label (Side)
7 GCOVAE557WJ3A AE X Bottom Cover (L)
8 GCOVAE558WJ3A AE X Bottom Cover (R)
9 LANGKD825WJ3W AE N X Terminal Angle (Side)
10 LANGKD876WJ3W AE N X Terminal Angle (Bottom)
11 LANGKD884WJ3W AF N X Stand Fix Angle, x2
12 LHLDWA124WJKZ AC J Wire Holder
13 LHLDZB989WJ3Z AC X WiFi Holder
14 PSPAZC690WJZZ AF J Gasket
15 PSPAZC691WJZZ AE J Gasket
16 PSPAZC805WJKZ AK J Cooler, x2
17 PSPAZC854WJKZ AK J Cooler
18 QCNW-N184WJZZ AD N X Connecting Cord (FFC 64Pin), x2
19 QCNW-N241WJZZ AT X Connecting Cord (LW)
20 QCNW-N243WJZZ AH X Connecting Cord (UB)
21 Q
CNW
-N675WJZZ AD X Connecting Cord (FFC 80Pin), x2
22 QCNW-N702WJZZ AL N X Connecting Cord (PD/PL)
23 RCORFA061WJZZ AG J Ferrite Core, x4
24 GCOVAE555WJ3A AD X AC Cord Cover
25 HiNDPF024WJZZ AC X Energy Guide Label
26 HiNDPF077WJSA AC N X Model Label
27 LHLDWA318WJKZ AD J Cable Tie
28 LX-BZA473WJN1 AC J Plastic Screw, x2
29 QCNW-M030WJZZ AE X Connecting Cord (SP)
30 QCNW-N242WJZZ AH X Connecting Cord (RA)
31 RSP-ZA615WJZZ AY J Speaker Unit (L)
32 RSP-ZA616WJZZ AY J Speaker Unit (R)
!
33 QACCDA084WJPZ AG X AC Cord
34 LX-EZA069WJF7 AA X Screw, x2
35 XBPS830P06WS0 AA X Screw, x20
37 XEBS830P12000 AA X Screw, x10
38 LHLDWA289WJKZ AA X Wire Holder
39 LHLDWA176WJUZ AB X Wire Holder
40 LHLDWA175WJUZ AA X Wire Holder
41 LX-BZA207WJF7 AA X Screw, x47

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
