Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
9
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[10] CABINET AND MECHANICAL PARTS (LC-60SQ10U)
1 CCABAD080WJ31 BL X Front Cabinet Ass'y
1-1 Not Available - N - Fronr Cabinet
1-2 Not Available - - R/C LED Decoration
1-3 HDECSA115WJ3A AR N X Shine Trim
1-4 LHLDWA175WJUZ AC J Wire Holder
1-5 LHLDWA289WJKZ AC J Wire Holder
1-6 TLABZD612WJ3C AB N X Licence Label
1-7 TLABZE228WJSC N X QUATTRON Label
2 CCABBC175WJ33 BE N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - N - Terminal Label (Bottom)
2-3 Not Available - - KEY Indication
2-4 Not Available - N - Terminal Label (side)
2-5 PSPAHC682WJZZ AB X Himeron
2-6 PSPAHC683WJZZ AB X Himeron, x2
3 CANGKD823WJ31 AE X VESA Angle Ass'y, x4
3-1 Not Available - N - VESA Angle
3-2 Not Available - - VESA Shaft
4 TLABNB037WJZZ AB X Serial Label (Back)
5 Not Available - N - Serial Label (Side)
6 LANGKD145WJFW AD X Terminal Angle (Side)
7 LANGKD146WJFW AC X Terminal Angle (Bottom)
8 LANGKD821WJ3W AF X Stand Fix Angle, x2
9 LHLDWA124WJKZ AC J Wire Holder, x2
10 LHLDWA175WJUZ AC J Wire Holder
11 LHLDWA289WJKZ AC J Wire Holder
12 LHLDZB951WJKZ AD J Power Spacer, x2
13 LX-BZA207WJF7 AA J Screw, x47
14 NSFTZA459WJF7 AC J Tray Shaft, x6
15 PSPAZC690WJZZ AF J Gasket
16 PSPAZC691WJZZ AE J Gasket
17 PSPAZC805WJKZ AK J Cooler, x2
18 QCNW-N184WJZZ AD N X Connecting Cord (FFC 64Pin), x2
19 QCNW-N236WJZZ AR X Connecting Cord (LW)
20 Q
CNW
-N675WJZZ AD X Connecting Cord (FFC 80Pin), x2
21 QCNW-N702WJZZ AL N X Connecting Cord (PD/PL)
22 RCORFA061WJZZ AG J Ferrite Core, x4
23 XBPS830P06WS0 AA J Screw, x19
24 GCOVAE552WJ3A AE X Bottom Cover (L)
25 GCOVAE553WJ3A AE X Bottom Cover (R)
26 GCOVAE555WJ3A AD X AC Cord Cover
27 HiNDPF019WJZZ AC N X Energy Guide Label
28 HiNDPF070WJSA AC N X Model Label
29 JBTN-A985WJ3A AC N X KEY Button
30 LHLDWA318WJKZ AD J Cable Tie
31 LHLDZB989WJ3Z AC X WiFi Holder
32 LX-BZA473WJN1 AC J Plastic Screw, x2
33 LX-EZA069WJF7 AB J Screw, x2
34 QCNW-M030WJZZ AE X Connecting Cord (SP)
35 QCNW-N242WJZZ AH N X Connecting Cord (RA)
36 QCNW-N243WJZZ AH N X Connecting Cord (UB)
37 RSP-ZA615WJZZ AY J Speaker Unit (L)
38 RSP-ZA616WJZZ AY J Speaker Unit (R)
40 XEBS830P12000 AA J Screw, x9
41 XEPS830P12WS0 AB J Screw, x3
!
42 QACCDA084WJPZ AG X AC Cord
