LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
11
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[11] CABINET AND MECHANICAL PARTS (LC-70SQ10U)
1 CCABAD081WJ31 BM N X Front Cabinet Ass'y
1-1 Not Available - N - Fronr Cabinet
1-2 Not Available - N - R/C LED Decoration
1-3 HDECSA116WJ3A AR N X Shine Trim
1-4 LHLDWA175WJUZ AC J Wire Holder, x2
1-5 TLABZD612WJ3C AB N X Licence Label
1-6 TLABZE228WJSC N X QUATTRON Label
1-7 PSPAHB013WJZZ X Himeron, x2
2 CCABBC177WJ33 BK N X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 Not Available - - Terminal Label (Bottom)
2-3 Not Available - N - Terminal Label (Side)
3 DCOVAE559WE01 AK X KEY Unit Ass'y
3-1 Not Available - N - KEY Button Cover
3-2 JBTN-A937WJ3A AZ J KEY Button
3-3 XEBS830P08000 AA J Screw, x2
4 CANGKD824WJ31 AE N X VESA Angle Ass'y, x4
4-1 Not Available - N - VESA Angle
4-2 Not Available - - VESA Shaft
5 TLABNB037WJZZ AB X Serial Label (Back)
6 Not Available - N - Serial Label (Side)
7 GCOVAE557WJ3A AE X Bottom Cover (L)
8 GCOVAE558WJ3A AE X Bottom Cover (R)
9 LANGKD825WJ3W AE N X Terminal Angle (side)
10 LANGKD876WJ3W AE N X Terminal Angle (Bottom)
11 LANGKD884WJ3W AF N X Stand Fix Angle, x2
12 LHLDWA124WJKZ AC J Wire Holder
13 LHLDWA175WJUZ AC J Wire Holder
14 LHLDWA176WJUZ AC J Wire Holder
15 LHLDWA289WJKZ AC J Wire Holder
16 LHLDZB989WJ3Z AC X WiFi Holder
17 LX-BZA207WJF7 AA J Screw, x47
18 PSPAZC690WJZZ AF J Gasket
19 PSPAZC691WJZZ AE J Gasket
20 P
SPA
ZC805WJKZ AK J Cooler, x2
21 PSPAZC854WJKZ AK J Cooler
22 QCNW-N184WJZZ AD N X Connecting Cord (FFC 64Pin), x2
23 QCNW-N241WJZZ AT X Connecting Cord (LW)
24 QCNW-N243WJZZ AH X Connecting Cord (UB)
25 QCNW-N675WJZZ AD X Connecting Cord (FFC 80Pin), x2
26 QCNW-N702WJZZ AL N X Connecting Cord (PD/PL)
27 RCORFA061WJZZ AG J Ferrite Core, x4
28 XBPS830P06WS0 AA J Screw, x20
29 GCOVAE555WJ3A AD X AC Cord Cover
30 HiNDPF024WJZZ AC N X Energy Guide Label
31 HiNDPF071WJSA AC N X Model Label
32 LHLDWA318WJKZ AD J Cable Tie
33 LX-BZA473WJN1 AC J Plastic Screw, x2
34 LX-EZA069WJF7 AB J Screw, x2
35 QCNW-M030WJZZ AE X Connecting Cord (SP)
36 QCNW-N242WJZZ AH X Connecting Cord (RA)
37 RSP-ZA615WJZZ AY J Speaker Unit (L)
38 RSP-ZA616WJZZ AY J Speaker Unit (R)
40 XEBS830P12000 AA J Screw, x10
!
41 QACCDA084WJPZ AG X AC Cord
