Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
23
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[17] CABINET AND MECHANICAL PARTS-2 (LC-60TQ15U)
1 CANGKD790WJ31 AW X BL Support Angle Ass'y (Bottom)
2 CHLDZB965WJ33 AQ N X P-Chassis Unit (Top)
3 CHLDZB966WJ33 AQ N X P-Chassis Unit (Bottom)
4 CHLDZB967WJ33 AN N X P-Chassis Unit (Left)
5 CHLDZB968WJ33 AN N X P-Chassis Unit (Right)
6 CANGKD506WJ31 AD X VESA Angle Ass'y, x4
7 CANGKD933WJ31 AS X BL Support Angle Ass'y (Top)
8 CCHSMA706WJ34 BT N X BL Chassis Unit Ass'y
9 HDECPA090WJZZ AC X Decoration Sheet (Side)
10 HDECPA091WJZZ AB X Decoration Sheet (Bottom)
11 LANGKD145WJFW AD X Terminal Angle (Side)
12 LANGKD146WJFW AC X Terminal Angle (Bottom)
13 LANGKD759WJ3W AF X Stand Fix Angle, x2
14 LHLDWA124WJKZ AC J Wire Holder
15 LHLDWA289WJKZ AC J Wire Holder, x2
16 LHLDZB981WJ3Z AE X S-PWB Holder (Left)
17 LHLDZB985WJ3Z AE X S-PWB Holder (Right)
18 LX-BZA207WJF7 AA J Screw, x31
19 LX-LZ0003TPZZ AC J Rivet, x6
20 PSPAZC690WJZZ AF J Gasket
21 PSPAZC691WJZZ AE J Gasket
22 PSPAZC805WJKZ AK J Cooler, x3
23 QCNW-M534WJZZ AG J Connecting Cord (SP2)
24 QCNW-M540WJZZ AN N X Connecting Cord (PD/PL)
25 QCNW-M854WJPZ AX J Connecting Cord (LW)
26 QCNW-N074WJQZ AP J Connecting Cord (L1)
27 QCNW-N676WJZZ AE X Connecting Cord (FFC 80p), x2
28 QCNW-N677WJZZ AE X Connecting Cord (FFC 64p), x2
29 RCORFA061WJZZ AG J Ferrite Core, x4
30 RUNTKB075WJZZ BB J LED Unit, x4
31 XBPS830P06WS0 AA J Screw, x19
32 DWAKMA031WE37 BY N X Aluminum Frame Ass'y
33 PGiDMA088WJZZ BH N X LGP
34 PMiR-A360WJ3A AX N X Reflector Sheet
35 P
SHE
PB245WJ3A AY X Diffuser
36 PSHEPB249WJZZ AZ J Lens Sheet
37 PSHEPB359WJZZ AW N X Lens Sheet
38 R1JE600D3HD6AZ N X 60" LCD PANEL Unit
39 TLABN2229TPZZ AA J MODULE Label
40 TLABN3860TPZZ AA X BL Label
42 XBPS830P08000 AA J Screw, x22

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
