Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
33
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[22] CABINET AND MECHANICAL PARTS-1 (LC-70UQ17U)
1 CCOVAE787WJ31 AY N X Front Cover Ass'y
1-1 Not Available - N - Front Cover
1-2 Not Available - N - LED Decration
1-3 Not Available - N - ShineTrim
2 CCABBC195WJ33 BK N X Rear Cabinet Ass'y
2-1 Not Available - - Rear Cabinet
2-2 Not Available - - Terminal Label (Back)
2-3 Not Available - - Terminal Label (Bottom)
2-4 Not Available - N - Terminal Label (Side)
2-5 LHLDWA318WJKZ AD J Cable Clamp
2-6 PSPAHB013WJZZ AB J Himeron, x2
2-7 PSPAHB356WJZZ AB J Himeron, x2
2-8 Not Available - - Himeron, x2
2-9 Not Available - - SP Box Seacer-A, x4
2-10 Not Available - - Himeron, x12
3 CCOVAE589WJ31 AP N X Bottom Cover Ass'y
3-1 Not Available - N - Bottom Cover
3-2 PSPAHB013WJZZ AB J Himeron, x2
3-3 Not Available - - Himeron, x4
4 CCOVAE513WJ31 AF N X KEY Cover Ass'y
4-1 Not Available - N - KEY Cover
4-2 Not Available - - Operation Label
4-3 JBTN-A984WJ3A AC N X KEY Button
5 TLABNB037WJZZ AB X Serial Label (BacK)
6 Not Available - N - Serial Label (Side)
7 GCOVAE790WJ3A AQ N X Decration Cover (Rear)
8 QCNW-M373WJQZ AG X Connecting Cord (SP1)
9 QCNW-N243WJZZ AH N X Connecting Cord (WB)
10 QCNW-N332WJZZ AK N X Connecting Cord (RA)
11 RSP-ZA572WJZZ AT J Speaker Unit, x2 (L/R)
12 RSP-ZA575WJZZ BB J Speaker Unit (Woofer)
13 XBPS830P06WS0 AA J Screw, x37
14 XEBS830P12000 AA J Screw, x12
15 GCOVAE555WJ3A AD X AC Cord Cover
16 H
iND
PF024WJZZ AC N X Energy Guide Label
17 HiNDPF048WJ3A N X Model Label
!
18 QACCDA084WJPZ AG X AC Cord

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
