Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
35
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[23] CABINET AND MECHANICAL PARTS-2 (LC-70UQ17U)
1 CANGKD762WJ31 AX X Suppot Angle Ass'y (Bottom)
2 CHLDZB969WJ33 AN N X P-Chassis Unit (Top-Left)
3 CHLDZB970WJ33 AN N X P-Chassis Unit (Top-Right)
4 CHLDZB971WJ33 AN N X P-Chassis Unit (Bottom-Left)
5 CHLDZB972WJ33 AN N X P-Chassis Unit (Bottom-Right)
6 CHLDZB973WJ33 AN N X P-Chassis Unit (Left)
7 CHLDZB974WJ33 AN N X P-Chassis Unit (Right)
8 CANGKD506WJ31 AD X VESA Angle Ass'y, x4
9 CANGKD761WJ31 AV X Support Angle Ass'y (Top)
10 CCHSMA676WJ38 BW N X BL Chassis Unit Ass'y
11 CHLDZB982WJ31 AE X S-PWB Holder, x4
12 HDECPA090WJZZ AC X Decration Sheet (Side)
13 HDECPA091WJZZ AB X Decration Sheet (Bottom)
14 LANGKD145WJFW AD X Terminal Angle (Side)
15 LANGKD146WJFW AC X Terminal Angle (Bottom)
16 LANGKD759WJ3W AF X Stand Fix Angle, x2
17 LHLDWA289WJKZ AC J Wire Holder
18 LX-BZA207WJF7 AA J Screw, x31
19 LX-LZ0003TPZZ AC J Rivet, x8
20 PSPAZC690WJZZ AF J Gasket
21 PSPAZC691WJZZ AE J Gasket
22 PSPAZC805WJKZ AK J Cooler, x3
23 QCNW-M534WJZZ AG J Connecting Cord (SP2)
24 QCNW-N075WJQZ AM J Connecting Cord (L1)
25 QCNW-N076WJQZ AN J Connecting Cord (L2)
26 QCNW-N241WJZZ AT X Connecting Cord (LW)
27 QCNW-N254WJZZ AQ X Connecting Cord (PD)
28 QCNW-N676WJZZ AE X Connecting Cord (FFC 80p), x2
29 QCNW-N677WJZZ AE X Connecting Cord (FFC 64p), x2
30 RCORFA061WJZZ AG J Ferrite Core, x4
31 RUNTKB077WJZZ BA J LED Unit, x6
32 XBPS830P06WS0 AA J Screw, x12
33 DWAKMA035WE37 N X Aluminum Frame Ass'y
34 LX-BZA202WJF8 AA J Screw, x8
35 P
GiD
MA089WJZZ BU N X LGP
36 PMiR-A362WJ3A AZ N X Reflector Sheet
37 PSHEPB252WJZZ BC J Lens Sheet
38 PSHEPB253WJZZ BT J DBEF Sheet
39 PSHEPB360WJZZ AZ N X Lens Sheet
40 QCNW-N118WJZZ AD X SG-FFC (Left)
41 QCNW-N119WJZZ AD X SG-FFC (Right)
42 R1JE695D3HB1AV N X 70" LCD PANEL Unit
43 TLABN2229TPZZ AA J MODULE Label
44 TLABN3860TPZZ AA X BL LABEL
46 XBPS830P08000 AA J Screw, x26
47 XBSS730P06000 AA J Screw, x2

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
