Sharp LC-60EQ10U Service Manual

LC-60/70EQ10U,SQ10U/15U/17U,TQ15U,UQ17U
5 – 14
[Adjustment standard value]
Measuring instrument: [TOPCON SR-UL2] Technical measuring instrument.
Level Reference value Adjustment spec Inspection spec
Point 7 928
X=0.272
±0.0010 ±0.0020
y=0.277
Point 6 784
X=0.2755
±0.0015 ±0.0030
y=0.2720
Point 5 624
X=0.2755
±0.0020 ±0.0040
y=0.2720
Point 4 432
X=0.2755
±0.0030 ±0.0060
y=0.2720
Point 3 304
X=0.2755
±0.0035 ±0.0070
y=0.2720
Point 2 192
X=0.2755
±0.0040 ±0.0080
y=0.2720
Remarks Setting conditions for inspection
AV MODE: [DYNAMIC] (Reset)
Monochro: ON
Active Backlight: OFF
Aging Time: Min. 60 minutes
Brightness specification after adjustment.
LC-60SQ10U,15U,17U/EQ10U/TQ15U:Min 240cd/m2
LC-70SQ10U,15U,17U/EQ10U/TQ15U:Min 240cd/m2
Adjustment
point
Adjustment conditions Adjustment procedure

Sharp LC-60EQ10U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	60 \
Display brightness	- cd/m²
Native aspect ratio	16:9
LED backlighting type	Edge-Lit LED
Contrast ratio (dynamic)	8000000:1
3D	No
Audio input	4
Teletext function	-
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	110 - 240 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Package depth	249 mm
Package width	1522 mm
Package height	946 mm
Package weight	36500 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	372 mm
Height (with stand)	861 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	445 mm
Weight (without stand)	25000 g
