Sharp LC-60LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
6 – 14
[External input HDMI-1/2/3/4] No picture on the display (11)
Does not the picture/sound of the HDMI signal input to HDMI-1/2/3/4 go out?
Is the Hot plug detection function output from pin [19] of the
HDMI-1 (SC1503) normal?
NO Check the line between SC1503 and pin [59] of IC1504 (HDMI-
SW).
Is the Hot plug detection function output from pin [19] of the
HDMI-2 (SC1502) normal?
NO Check the line between SC1502 and pin [74] of IC1504 (HDMI-
SW).
Is the Hot plug detection function output from pin [19] of the
HDMI-3 (SC1501) normal?
NO Check the line between SC1501 and pin [55] of IC1504 (HDMI-
SW).
Is the Hot plug detection function output from pin [19] of the
HDMI-4 (SC1505) normal?
NO Check the line between SC1505 and pin [50] of IC1504 (HDMI-
SW).
YES
NO
Check the setting of an external input device that connects with
HDMI-1/2/3/4.
Is EDID data pins [58/HDMI1_SCL, 57/HDMI1_SDA] of IC1504
accessed, and is it read from pins [15, 16] of a HDMI-1
(SC1503)?
NO Is access possible in the exchange of IC1504?
Is EDID data pins [73/HDMI2_SCL, 72/HDMI2_SDA] of IC1504
accessed, and is it read from pins [15, 16] of a HDMI-2
(SC1502)?
NO
Is EDID data pins [54/HDMI3_SCL, 53/HDMI3_SDA] of IC1504
accessed, and is it read from pins [15, 16] of a HDMI-3
(SC1501)?
Check the peripheral circuit of SC1501/1502/1503/1505 and
IC1504.
Is EDID data pins [49/HDMI4_SCL, 48/HDMI4_SDA] of IC1504
accessed, and is it read from pins [15, 16] of a HDMI-4
(SC1505)?
YES
Do TMDS signals input to pins [26&27/
HDMI1_CLKNP_222.75MHz, 28&29/HDMI1_D0NP, 30&31/
HDMI1_D1NP, 32&33/HDMI1_D2NP] of IC1504?
NO Check the line between HDMI-1 (SC1503) and IC1504.
Do TMDS signals input to pins [17&18/
HDMI2_CLKNP_222.75MHz, 19&20/HDMI2_D0NP, 21&22/
HDMI2_D1NP, 23&24/HDMI2_D2NP] of IC1504?
NO Check the line between HDMI-2 (SC1502) and IC1504.
Do TMDS signals input to pins [8&9/
HDMI3_CLKNP_222.75MHz, 10&11/HDMI3_D0NP, 12&13/
HDMI3_D1NP, 14&15/HDMI3_D2NP] of IC1504?
NO Check the line between HDMI-3 (SC1501) and IC1504.
Do TMDS signals input to pins [99&100/
HDMI4_CLKN_222.75MHz, 1&2/HDMI4_D0NP, 3&4/
HDMI4_D1NP, 5&6/HDMI4_D2NP] of IC1504?
NO Check the line between HDMI-4 (SC1505) and IC1504.
YES
Do TMDS signals output from pins [87&86/
SW_TMDS_CLKNP_222.75MHz_, 85&84/SW_TMDS_D0NP_,
83&82/SW_TMDS_D1NP_, 81&80/SW_TMDS_D2NP_] of
IC1504 respectively?
NO Check the IC1504 and peripheral circuits.
YES
Do TMDS signals input to pins [AM9&AL9/
SW_TMDS_CLKNP_222.75MHz, AM10&AL10/
SW_TMDS_D0NP, AM11&AL11/SW_TMDS_D1NP,
AM12&AL12/SW_TMDS_D2NP] of IC3303 (Digital AV decode &
Main CPU)?
NO Check the line between IC3303 and IC1504.
YES
Refer to “Refer to “No picture on the display (1)” or “The sound is not emitted from the Speaker.”

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
