LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
4 – 1
LC60LE740E
Service Manual
CHAPTER 4. REMOVING OF MAJOR PARTS
[1] The location putting on the heat measure sheet
1. MAIN PWB Unit
LC-60/70LE740E/RU,741E/S,743E,LC-60LE840E/RU,841E/S,843E
LC-80LE645E/RU,646E/S,648E
PSPAZC805WJKZLC-60LE740E/RU, 741E/S,743E
LC-60LE840E/RU, 841E/S,843E
PSPAZC887WJKZLC-70LE740E/RU, 741E/S,743E
(7) Stick***
PSPAZC871W JKZ
COOLING SHEE T
for Main(25x25 t11)
