LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
v
IC For Exclusive Use Of The Service
Service Jigs
• (LC-60/70LE740E/RU,741E/S,743E)
• (LC-60LE840E/RU,841E/S,843E)
• (LC-80LE645E/RU,646E/S,648E)
Ref No. Parts No. Description Q'ty
IC2001 RH-iXD241WJNWQ IC R5F21368CNFP (Monitor Microprocessor) 1
Ref No. Parts No. Description
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L608WJQZ Connecting Cord L=1000mm, Main to POWER Unit (PD) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L610WJQZ Connecting Cord L=1000mm, Main to ICON Unit (CI) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L613WJQZ Connecting Cord L=1060mm, Main to Speaker Unit L/R (SP) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L587WJQZ Connecting Cord L=1000mm, Main to LCD Control Unit (PL) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L629WJQZ Connecting Cord L=1000mm, Main to LCD Control Unit (LW) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L582WJQZ Connecting Cord L=1000mm, Main to KEY/3D-IR Unit (RC) (LC-60LE740E/RU,741E/S,743E)
N QCNW-M029WJQZ Connecting Cord L=1000mm, Main to POWER Unit (PD) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M034WJQZ Connecting Cord L=1000mm, Main to ICON Unit (CI) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M030WJQZ Connecting Cord L=1060mm, Main to Speaker Unit L/R (SP) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M031WJQZ Connecting Cord L=1000mm, Main to LCD Control Unit (PL) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M168WJQZ Connecting Cord L=1000mm, Main to LCD Control Unit (LW) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M167WJQZ Connecting Cord L=1000mm, Main to KEY/3D-IR Unit (RC) (LC-70LE740E/RU,741E/S,743E)
Ref No. Parts No. Description
N QCNW-M539WJQZ Connecting Cord Main to POWER/LED Driver Unit and LCD Control Unit (PD)
N QCNW-K597WJQZ Connecting Cord Main to Woofer (SB)
N QCNW-K595WJQZ Connecting Cord Main to Speaker Unit L/R (SP)
N QCNW-F676WJQZ Connecting Cord Main to LCD Control Unit (LW)
N QCNW-L796WJQZ Connecting Cord Main to ICON Unit (CI)
N QCNW-C222WJQZ Connecting Cord 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ Connecting Cord 64pins, LCD Control Unit to LCD Panel Unit, x2
Ref No. Parts No. Description
N QCNW-C222WJQZ Connecting Cord 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L795WJQZ Connecting Cord Main to POWER Unit (PD)
N QCNW-L796WJQZ Connecting Cord Main to ICON Unit (CI)
N QCNW-L595WJQZ Connecting Cord Main to Speaker Unit L/R (SP)
N QCNW-G405WJQZ Connecting Cord Main to LCD Control Unit (PL)
N QCNW-F676WJQZ Connecting Cord Main to LCD Control Unit (LV)

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
