Sharp LC-60LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
iv
LC60LE740E
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
• (LC-60/70LE740E/RU,741E/S,743E)
NOTE: (*1) Replace MAIN Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.
• (LC-60LE840E/RU,841E/S,843E)
• (LC-80LE645E/RU,646E/S,648E)
NOTE: (*1) Replace MAIN Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.
OTHER Unit
Ref No. Parts No. Description
N DKEYDF733FM65 MAIN Unit (LC-60/70LE740E,RU)
N DKEYDF733FM66 MAIN Unit (LC-60/70LE741E,S)
N DKEYDF733FM68 MAIN Unit (LC-60/70LE743E)
N DUNTKF494FM02 R/C OPC Unit
N DUNTKF770FM51 ICON Unit
N DUNTKF800FM52 KEY Unit
N DUNTKG031FM51 LCD control Unit (LC-60LE740E/RU,741E/S,743E)
N DUNTKG031FM52 LCD control Unit (LC-70LE740E/RU,741E/S,743E)
N RUNTKA819WJQZ 3D-IR Transmitter Unit
N RUNTKA932WJQZ POWER Unit (LC-60LE740E,RU/741E,S/743E)
N RUNTKA933WJN1 POWER Unit (LC-70LE740E,RU/741E,S/743E)
Ref
No.
PARTS CODE DESCRIPTION
N DKEYDF733FM69 MAIN Unit (LC-60LE840E/RU)
N DKEYDF733FM70 MAIN Unit (LC-60LE841E/S)
N DKEYDF733FM71 MAIN Unit (LC-60LE843E)
N DUNTKG015FM51 R/C OPC Unit
N DUNTKG014FM51 ICON Unit
N DUNTKF800FM52 KEY Unit
N DUNTKG017FM51 3D-IR Transmitter Unit
N DUNTKF906FM56 LCD control Unit
N RUNTKA946WJQZ POWER/LED Driver Unit
Ref No. Parts No. Description
N DKEYDF733FM62 MAIN Unit (LC-80LE645E/RU)
N DKEYDF733FM63 MAIN Unit (LC-80LE646E/S)
N DKEYDF733FM64 MAIN Unit (LC-80LE648E)
N DUNTKF494FM02 R/C OPC Unit
N DUNTKF770FM53 ICON Unit
N DUNTKF800FM52 KEY Unit
N RUNTKA903WJQZ POWER Unit
Ref
No.
PARTS CODE DESCRIPTION
N R1LK600D3GV00Y 60" LCD Panel Module (LK600D3GV00Y) (LC-60LE740E/RU,741E/S,743E)
N R1LK695D3GW80F 70" LCD Panel Module (LK695D3GW80F) (LC-70LE740E/RU,741E/S,743E)
N CLCDTA257WE01 60" LCD Panel Module Unit (LC-60LE840E/RU,841E/S,843E)
N CLEDSV257WE01 LED Assembly(LC-60LE840E/RU,841E/S,843E)
N R1LK600D3GV10Y 60" LCD Panel (LK600D3GV10Y) (LC-60LE840E/RU,841E/S,843E)
N R1LK800D3GW10V 80" LCD Panel Module Unit (LK800D3GW10V) (LC-80LE645E/RU,646E/S,648E)

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
