Sharp LC-60LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
6 – 28
No sound from external input devices (5)
Does not the sound of the audio signal input to HDMI1/2/3/4 go out?
Please Refer to “[External input HDMI-1/2/3/4] No picture on the display (11)”.
No sound from external output device (1)
No audio signal output to EXT1 terminal.
Do audio signals output from pins [1/AUDIO_OUT_R, 3/
AUDIO_OUT_L] of EXT1 (SC505)?
YES Check the setting of an external input device that connects with
EXT1.
NO
Is AUDIO_MUTE(MUTE_A_ALL) [23 pin] of IC2001 (UCOM) at
“H”?
YES Check the peripheral circuits of IC2001 and AUDIO_MUTE.
(Q502 etc...)
NO
Do audio signals output from pins [1/TUNER_R_OUT, 7/
TUNER_L_OUT] of IC2706 (Buffer AMP)?
YES Check the line between IC2706 and SC505.
NO
Do audio signals input to pins [2, 6] of IC2706? YES Check IC2706 and its peripheral circuits.
NO
Do audio signals (TUNER_OUTR/L) output from pins [AG31/
TUNER_OUT_R, AG32/TUNER_OUT_L] of IC3303 (Digital AV
decode & Main CPU)?
YES Check between IC3303 and IC2706.
NO
Check IC3303 and its peripheral circuits.

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
