Sharp LC-60LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
4
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[7] CABINET AND MECHANICAL PARTS (LC-60LE740E,RU/741E,S,743E)
1 CCABAC821WJ12 N P Front Cabinet Ass'y
1-1 GCABAC821WJ1A N P Front Cabinet
1-2 GCOVAD966WJ1A P R/C OPC Cover
1-3 HDECQB671WJ2B N P Front Decoration
1-4 PSHEPB131WJKZ P ICON Decoration
2 CCABBC031WJ13 N P Rear Cabinet Ass'y (except LC-60LE741E/S)
2 CCABBC031WJ14 N P Rear Cabinet Ass'y (for LC-60LE741E/S)
2-1 GCABBC031WJ1A P Rear Cabinet
2-2 HiNDPE032WJSB P Indicator (Bottom) (except LC-60LE741E/S)
2-2 HiNDPE122WJSB P Indicator (Bottom) (for LC-60LE741E/S)
2-3 HiNDPE035WJSB P Indicator (Back)
2-4 HiNDPE117WJSB P Indicator (Side)
2-5 PSPAHC573WJZZ N P Himeron
2-6 PSPAHC574WJZZ N P Himeron
2-7 PSPAHC575WJZZ N P Himeron
3 CANGKD484WJ31 N P Vese Angke Ass'y, x4
3-1 LANGKD484WJ3W N P Vese Angke
3-2 NSFTZA471WJFN P Vese Shaft
4 CANGTA589WJ11 N P Angle BL Ass'y
4-1 LANGTA589WJ1W P Angle BL
5 CANGTA590WJ11 N P Angle BC Ass'y, x2
5-1 LANGTA590WJ1W P Angle BC
6 CANGTA591WJ11 N P Angle BR Ass'y
6-1 LANGTA591WJ1W P Angle BR
7 GCOVAD981WJ2A AH J AC Cord Cover
8 GCOVAE320WJ3A N P Bottom Cover, x2
9 GCOVAE430WJ2A N P KEY Cover
10 JBTN-A936WJ2A P KEY Button
11 LANGKD127WJFW AD J Angle
12 LANGKD148WJFW P Term Angle Bottom (except LC-60LE741E/S)
12 LANGKD192WJFW P Term Angle Bottom (for LC-60LE741E/S)
13 LANGKD611WJ3W N P Stand Angle, x2
14 LANGTA586WJ1W N P Angle (TOP)
15 LANGTA587WJ1W N P
Angle (L)
16 LANGTA588WJ1W N P Angle
17 LHLDWA294WJUZ AC J WireHolder
18 LHLDWA303WJKA AE J Cable Clamp
19 LHLDWA347WJKZ N P WireHolder, x8
20 LX-BZA207WJF7 AA J Screw, x19
21 LX-BZA473WJN1 N P Screw, x2
22 LX-NZA049WJFN AC J Screw (except LC-60LE741E/S)
23 NSFTZA459WJF7 AC J Tray Shaft, x6
24 PMLT-A676WJZZ P Gasket (HDMI)
25 PSLDMB651WJZZ P Conductive, x2
26 PSLDMB751WJFW P Main PWB Shield
27 PSPAGA963WJZZ P PC Sheet
28 PSPANA044WJKZ AB J Power PWB Spacer, x5
29 PSPAZC690WJZZ P Spacer
30 PSPAZC691WJZZ AE J Spacer, x3
31 PSPAZC805WJKZ N P Spacer, x2
32 PSPAZC836WJ2Z P Bottom Cover Spacer, x2
33 PZETKA595WJKZ P AC Cord Barrier
!
34 QACCKA055WJPZ AQ J AC Cord (except LC-60LE741E)
!
34 QACCBA106WJPZ AS J AC Cord (for LC-60LE741E)
35 QCNW-L587WJQZ AE J Connecting Cord (PL)
36 QCNW-L608WJQZ AM J Connecting Cord (PD)
37 QCNW-L610WJQZ AL J Connecting Cord (CI)
38 QCNW-L613WJQZ AH J Connecting Cord (SP)
39 QCNW-L629WJQZ AY J Connecting Cord (LW)
40 QCNW-M582WJQZ N P Connecting Cord (RC)
41 QCNWN2731TPZZ AF J FFC, x2
42 QEARZ0057CEFW AB J Spring
43 RCORF0103CEZZ AK J Core
44 RSP-ZA576WJZZ AT N J Speaker (L)
45 RSP-ZA577WJZZ AT N J Speaker (R)
46 TLABNC117WJZZ P Model Label
47 TLABZC453WJZZ P Plane Label
48 TLABZD130WJZZ N P Energy Label (except LC-60LE740RU)
49 XBPS830P06WS0 AA J Screw, x66
50 XEBS830P08000 AA J Screw, x3
51 XEBS830P12000 AA J Screw, x9

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
