Sharp LC-60LE740E User Manual

LC-60/70LE740E/RU,741E/S,743E,60LE840E/RU,841E/S,843E,80LE645E/RU,646E/S,648E
18
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[14] SUPPLIED ACCESSORIES/PACKING PARTS (LC-80LE645E/RU,646E/S,648E)
X1 CDAi-A806WJ32 N P Stand Base Ass'y
X2 CANGKD276WJ07 N P Stand Support Ass'y, x2
X3 CSAKKA011WJ03 N P Stand Screw Ass'y
X4 Ki-OUA003WJQZ P USB Dongle
X5 RRMCGB010WJSA P Remote Control (except LC-80LE648E)
X5 RRMCGB011WJSA P Remote Control (for LC-80LE648E)
X6 TCAUZA446WJZZ P Weee Sheet (except LC-80LE645RU)
X7 TCAUZA458WJN1 P Wi-Fi Sheet
X8 TCAUZA477WJZZ N P Safety Sheet
X9 TiNS-F431WJZZ N P Operation Manual
X10 Not Available - - "AAA" Size Battery, x2
X11 UiMCUA007WJQZ2 N P USB Memory
X12 TCAUZA493WJZZ N P Gost Sheet (for LC-80LE645RU)
X13 TGAN-B651WJZZ P Guarantee Sheet (for LC-80LE645RU)
X14 TGAN-A801WJN1 P Guarantee Sheet (for LC-80LE6456E)
X15 TGAN-A802WJN1 P Guarantee Sheet (for LC-80LE6456E)
!
X16 QACCKA061WJPZ P AC Cord (except LC-80LE646E)
!
X16 QACCBA111WJPZ P AC Cord (for LC-80LE646E)
S1 SPAKCG664WJZZ - N - Packing Case (NOT REPLACEMENT ITEM)
S2 SPAKCG665WJZZ - N - Packing Case (Bottom) (NOT REPLACEMENT ITEM)
S3 SPAKFC183WJZZ - N - Front Pad Base (NOT REPLACEMENT ITEM)
S4 SPAKPB792WJZZ - - Miror Mat (Base) (NOT REPLACEMENT ITEM)
S5 SPAKPB793WJZZ - - Miror Mat (Support) (NOT REPLACEMENT ITEM)
S6 SPAKPB843WJZZ - N - Polyethylene Bag (NOT REPLACEMENT ITEM)
S7 SPAKXD581WJZZ - N - Pad Top (NOT REPLACEMENT ITEM)
S8 SPAKXD582WJZZ - N - Pad Bottom (NOT REPLACEMENT ITEM)
S9 SPAKXD583WJZZ - N - Front Pad (NOT REPLACEMENT ITEM)
S10 SSAKAA111WJZZ - - Polyethylene Bag (NOT REPLACEMENT ITEM)
S11 SSAKKA011WJ2Z - - Packing Add. (Screw) (NOT REPLACEMENT ITEM)
S12 TLABM5584BMZZ - - Case No Label (NOT REPLACEMENT ITEM)
S13 TLABZC826WJZZ - - Bar Code Label (NOT REPLACEMENT ITEM)
[15] SERVICE JIG (USE FOR SERVICING) (LC-60/70LE740E/RU,741E/S,743E)
N QCNW-C222WJQZ J Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L608WJQZ J
Connecting Cord L=1000mm, Main to POWER Unit (PD) (LC-60LE740E/RU,741E/
S,743E)
N QCNW-L610WJQZ J Connecting Cord L=1000mm, Main to ICON Unit (CI) (LC-60LE740E/RU,741E/S,743E)
N QCNW-L613WJQZ J
Connecting Cord L=1060mm, Main to Speaker Unit L/R (SP) (LC-60LE740E/RU,741E/
S,743E)
N QCNW-L587WJQZ J
Connecting Cord L=1000mm, Main to LCD Control Unit (PL) (LC-60LE740E/RU,741E/
S,743E)
N QCNW-L629WJQZ J
Connecting Cord L=1000mm, Main to LCD Control Unit (LW) (LC-60LE740E/RU,741E/
S,743E)
N QCNW-L582WJQZ J
Connecting Cord L=1000mm, Main to KEY/3D-IR Unit (RC) (LC-60LE740E/RU,741E/
S,743E)
N QCNW-M029WJQZ J
Connecting Cord L=1000mm, Main to POWER Unit (PD) (LC-70LE740E/RU,741E/
S,743E)
N QCNW-M034WJQZ J Connecting Cord L=1000mm, Main to ICON Unit (CI) (LC-70LE740E/RU,741E/S,743E)
N QCNW-M030WJQZ J
Connecting Cord L=1060mm, Main to Speaker Unit L/R (SP) (LC-70LE740E/RU,741E/
S,743E)
N QCNW-M031WJQZ J
Connecting Cord L=1000mm, Main to LCD Control Unit (PL) (LC-70LE740E/RU,741E/
S,743E)
N QCNW-M168WJQZ J
Connecting Cord L=1000mm, Main to LCD Control Unit (LW) (LC-70LE740E/RU,741E/
S,743E)
N QCNW-M167WJQZ J
Connecting Cord L=1000mm, Main to KEY/3D-IR Unit (RC) (LC-70LE740E/RU,741E/
S,743E)
[16] SERVICE JIG (USE FOR SERVICING) (LC-60LE840E/RU,841E/S,843E)
N QCNW-M539WJQZ J Connecting Cord Main to POWER/LED Driver Unit and LCD Control Unit (PD)
N QCNW-K597WJQZ J Connecting Cord Main to Woofer (SB)
N QCNW-K595WJQZ J Connecting Cord Main to Speaker Unit L/R (SP)
N QCNW-F676WJQZ J Connecting Cord Main to LCD Control Unit (LW)
N QCNW-L796WJQZ J Connecting Cord Main to ICON Unit (CI)
N QCNW-C222WJQZ J Connecting Cord 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L214WJQZ J Connecting Cord 64pins, LCD Control Unit to LCD Panel Unit, x2
[17] SERVICE JIG (USE FOR SERVICING) (LC-80LE645E/RU,646E/S,648E)
N QCNW-C222WJQZ J Connecting Cord 80pins, LCD Control Unit to LCD Panel Unit, x2
N QCNW-L795WJQZ J Connecting Cord Main to POWER Unit (PD)
N QCNW-L796WJQZ J Connecting Cord Main to ICON Unit (CI)
N QCNW-L595WJQZ J Connecting Cord Main to Speaker Unit L/R (SP)
N QCNW-G405WJQZ J Connecting Cord Main to LCD Control Unit (PL)
N QCNW-F676WJQZ J Connecting Cord Main to LCD Control Unit (LV)

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
