5 – 5
14/21
1 TCON Version EXT.1 xxxxx
2 TCON Version EXT.2
3 TCON Version EXT.3
4 TCON Version EXT.4
15/21
1 3DHDMI FPGA Version xxxxx
22D→3D FPGA Version xxxxx
3 3D LED BRIGHTNESS xxxxx
4 3D IR EMITTER CONTROL xxxxx
16/21 [FR REGI]
1 CROSSTALK ADJ MODE Enter
2 CROSSTALK TH1
3 CROSSTALK TH2
4 CROSSTALK TH3
5 CROSSTALK TH4
6 CROSSTALK GAIN1
7 CROSSTALK GAIN2
8 CROSSTALK GAIN3
17/21
1 WIFI SSID 2.4GHz xxxxx
2 WIFI SSID 5 GHz xxxxx
3 WIFI RSSI 2.4GHz xxxxx
4 WIFI RSSI 5 GHz xxxxx
5 WIFI TIME 5 GHz xxxxx
6 WIFI RSSI TEST xxxxx
7 WIFI RSSI RESULT xxxxx
18/21
1 READ/WRITE READ Read/Write
2 SLAVE/ADDRESS SLAVE0 Slave address
3 REGISTER ADDRESS 0x 0
0x 0
Register address
4WRITE DATA 0x 0
0x 0
Writing data
5 READ DATA 0x 0
0x 0
Reading data
19/21
1 RF AGC BG 6 RF-AGC BG adjustment execution
2 RF AGC DK 5 RF-AGC DKG adjustment execution
3 RF AGC I 6 RF-AGC I adjustment execution
4 RF AGC L/L' 4 RF-AGC L/L' adjustment execution
20/21 [ETC]
1 ERROR STANDBY CAUSE1 NO RECORD ERROR STANDBY CAUSE
2 ERROR STANDBY CAUSE2 NO RECORD
3 ERROR STANDBY CAUSE3 NO RECORD
4 ERROR STANDBY CAUSE4 NO RECORD
5 ERROR STANDBY CAUSE5 NO RECORD
6 STANDBY CAUSE RESET OFF Reset stand by cause.
21/21 [ETC]
1 EEP SAVE OFF Writing setting values to EEPROM.
2 EEP RECOVER OFF Reading setting values from EEPROM.
3 MONITOR ERROR CAUSE RESET OFF Reset of monitor error cause
4 MODEL NAME LE740E MODEL NAME
5 PANEL SIZE 70 Panel size setting.
6 VERUP FLAG ENABLE Enter Verup Flag
7 PANEL LIMIT ON PANEL LIMIT
8 PANEL RANGE LIMIT xxx PANEL RANGE LIMIT
9 SHORT CHECK MODE Enter Check LED Back light
10 SHORT CHECK CURRENT 60
11 CURRENT SW LOW
12 PRODUCT EEP ADR 0x 0 Don't touch when serving (for producer of factory)
13 PRODUCT EEP DATA 0x 0 Don't touch when serving (for producer of factory)
14 PRODUCT FACTORY 1 Don't touch when serving (for producer of factory)
15 TEST NETWORK UPDATE No
Page Line Item Description Remarks (adjustment detail, etc.)

Sharp LC-60LE740E Specifications

General

Display diagonal	60 \
Display brightness	- cd/m²
Native refresh rate	100 Hz
Supported video modes	1080p
Viewing angle, vertical	176 °
Display diagonal (metric)	152 cm
Supported graphics resolutions	1920 x 1080 (HD 1080)
Dynamic contrast ratio marketing name	Mega Contrast
3D	Yes
Volume control	Digital
Headphone connectivity	3.5 mm
Annual energy consumption	146 kWh
Mean time between failures (MTBF)	40000 h
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T
Audio decoders	Dolby Digital, Dolby Digital Surround EX, Dolby Virtual Speaker
RMS rated power	20 W
Built-in subwoofer	No
Number of speakers	2
HDCP	-
HDMI version	1.4
Composite video in	0
HDMI ports quantity	4
USB 2.0 ports quantity	1
Compatible memory cards	SD
Audio formats supported	AAC
Video formats supported	DIVX, H.264, MPEG4
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.1 W
Power consumption (typical)	100 W

Weight and Dimensions

Depth (with stand)	333 mm
Height (with stand)	872 mm
Depth (without stand)	72 mm
Width (without stand)	1383 mm
Height (without stand)	839 mm
Weight (without stand)	29500 g
