CONFIDENTIAL – DO NOT COPY
Page 6-2
File No. SG-0000239
JA1 CONNECTION [Main BD to SPEAKER ]
Pin Description
1 R+
2 R-
3 L+
4 L-
JL1 CONNECTION [Main BD to Panel Side]
Pin Description
1 LVDSVDD
2 LVDSVDD
3 LVDSVDD
4 LVDSVDD
5 NC
6 GND
7 GND
8 GND
9 NC
10 NC
11 B4M
12 B4P
13 B3M
14 B3P
15 GND
16 BCKM
17 BCKP
18 GND
19 B2M
20 B2P
21 B1M
22 B1P
23 B0M
24 B0P
25 NC
26 NC
27 A4M
28 A4P
