Page 6-3
File No. SG-0000239
29 A3M
30 A3P
31 GND
32 ACKM
33 ACKP
34 GND
35 A2M
36 A2P
37 A1M
38 A1P
39 A0M
40 A0P
41 GND
42 SCN_EN
43 LD_EN
44 NC
45 LVDS_FORMAT
46 NC
47 NC
48 Tcon_SDA
49 Tcon_WP
50 Tcon_SCL
51 NC
JL2
CONNECTION [Main BD to Panel Side]
Pin Description
1 GND
2 GND
3 D4M
4 D4P
5 D3M
6 D3P
7 GND
8 DCKM
9 DCKP
10 GND
11 D2M
12 D2P
