CONFIDENTIAL – DO NOT COPY
Page 6-4
File No. SG-0000239
13 D1M
14 D1P
15 D0M
16 D0P
17 GND
18 GND
19 C4M
20 C4P
21 C3M
22 C3P
23 GND
24 CCKM
25 CCKP
26 GND
27 C2M
28 C2P
29 C1M
30 C1P
31 C0M
32 C0P
33 GND
34 NC
35 NC
36 NC
37 NC
38 NC
39 NC
40 NC
41 NC
