Sharp LMV Series User Manual

3
SHARP VARIABLE SPEED MILLING MACHINE
1. Specifications:
STANDARD
SPECIFICATION
INCH
MM
SPECIFICATION
INCH
MM
WORK TABLE
Spindle speed
RPM
50HZ
60HZ
50-3750 rpm
60-4500 rpm
Working area of table
49 x 9
Machine Net Weight
1.01 kg
Table Travel
36.6
Saddle Travel
12
Knee Travel
16
HEAD
Motor
2HP 3HP
Spindle Taper
R8 or N.S.T # 30
Quill Travel
5
127
Feed Rate per
Revolution
0.0015, 0.003,
0.006
0.04, 0.08,
0.15
OPTIONAL
Working Area of Table
49 x 9
1245 x 230 Table Travel (Head)
36%
933
2. Machine uses:
1. Drilling
2. Milling
3. Molding
4. Polishing
5. Boring
6.
