4
3.
Machine parts:
1.
Headstock:
Power Feed Engagement Crank (I) High/Low Lever (J)
Speed
Selector (G)
Brake
Quill Feed
Selector (C)
Feed
Reverse
Knob (D)
Feed
Handwheel
(E)
Quill Feed
Lever (H)
Micrometer
Adjustment
Nut (K)
Quill Lock
(L)
Feed Control Lever (F)
