Sharp LMV Series User Manual

41
NO.
PART NO.
DESCRIPTION
SPECIFICATION
Q'TY
1
1500-C035
Table
9"×49"
1
2
1500-D011
Left Bearing Bracket
1
3
HADA-W10141
Bolt
3/8"×1"
16
4
HPB-0530
Overload Clutch Lever Spring Plunger
Ø 6×25
6
5
BR-51105
Bearing
51105
4
6
AW05-25MM
Lock Washer
AW05
2
7
HAN05
Locknut Washer
AN05
2
8
1500-D021
Dial Holder
2
9
1500-D016
Dial (Mertic Graduation 250mm)
3
10
1500-D006
Dial Nut
3
11
1500-D026
Three handle
3
12
1500-C086
Ball Crank Handle Lever
3
13
HBBE-W040-13
Nut
1/2"
3
14
1500-D012A
Right Bearing Bracket
1
15
BR-6204
Bearing
6204
1
16
1500-D005
Dial Holder
1
17
1500-C031
Stop Piece T-Bolt
2
18
1500-C032
Table Stop Piece
2
19
1500-C073
Washer
2
20
HBBE-W030-16
Nut
3/8"
2
21
1500-D022C
Feed Nut Bracket
1
22
HPB-0530
Overload Clutch Lever Spring Plunger
Ø 5×30
2
23
1500-D033A
Longitudinal Feed Nut (Metric)
1
24
HKE-2R-5550
Flat Key
5×5×50
2
25
1500-D017
Backlash Adjustment Nut
2
26
1500-D018
Solid lock nut
2
27
1500-D032D
Longitudinal Feed Screw (Metric able)
Ø 32×1503.6
1
28
HKE-2R-3320
Flat Key
3×3×20
2
29
HKE-2R-3325
Flat Key
3×3×25
1
30
1500-D035A
Cross Feed Screw (Metric)
Ø 32×604.5
1
31
1500-D034A
Cross Feed Screw Nut (Metric)
1
32
1500-D028A
Cross Feed Bearing Bracket
1
33
1500-C052C
Saddle
1
34
1500-C043
Saddle Table Gib
1
35
1500-C041A
Adjusting Screw
4
