Sharp MX-2310U

11
1 2
3
5
4
9 10 11 12
7
8
6
1 Automatic document feeder
2 Front cover
3 Output tray (Center tray)
4 Operation panel
5 Right tray
6 [POWER] key ( )
7 Bypass tray
8 Main power switch
9 Tray 1
10 Tray 2 (when paper feed tray is installed)*
11 Tray 3 (when paper feed tray is installed)*
12 Tray 4 (when paper feed tray is installed)*
* Peripheral device.
Part Names
