PRINT IMAGE POSITION & BK MAGNIFICATION:
Check Print Image Off Centre & Lead Edge position - Use Sim 50-10:-
Inside dimension of the printed halftone must be 240±0.5mm.
Lead edge void area 4.0 ± 1.0mm.
Rear edge void area 2.0mm - 5.0mm.
Front & Rear Void areas 2.0 ± 2.0mm.
If NG, perform the following adjustments as required:-
Sim 50-10 BK MAG / Image Off Centre Adjustment (All Trays).
Sim 50-05 Printer Lead Edge & Void Adjust.
Sim 50-28 BK MAG ADJ (Main Scan Mag).
SETUP/PRINT ADJ (Lead, Offset or All).
IMAGE SKEW & COLOUR REGISTRATION
Sim 50-22 Colour Registration/Skew & OPC Drum Phase Adjustment:
Check/Adjust SKEW (CMY) so value is Close to 0 as possible (Result=OK).
HALF TONE F/R EVENNESS & COLOUR CALIBRATION
Sim 61-13 F/R Evenness Correction Data Clear.
Sim 61-11 F/R Evenness Correction Adjustment.
Sim 46-74 Engine & Printer Colour Calibration: Select FACTORY Mode.
IMAGE QUALITY CHECK [COPY & PRINT]
Check Image Quality (Copy Mode) – Density, Magnification, Lead Edge & Void.
If NG, perform the following adjustments as required:-
Sim 46-01 Copy Density Adjust. (Colour).
Sim 46-02 Copy Density Adjust. (B/W).
Sim 46-09 SPF Copy Density Adjust.
Manual Adjustment (Magnification, Lead Edge, Void, Off Centre etc):
Sim 48-01 Magnification Adjustment (OC & SPF).
Sim 50-01 Lead/Rear Edge, Loss & Void Adjust.
Sim 50-12 OC & SPF Off Centre Adjust.
Sim 50-28 OC ADJUST (Lead, Offset & Mag).
SPF ADJ:(Lead, Offset & Sub scan).
Check Print Image Quality:
Sim 64-05 PCL Density Test Page
Sim 64-06 PS Density Test Page
