Sharp MX-3070N

SHARP
TROUBLE CODES
59
A0
Program Trouble
01
PCU ROM abnormality
02
SCU ROM abnormality
04
ACU/ACRE ROM error
10
MFP ROM error
15
Incompatible DSK Boot and program
firmware version
17
UI data & CPU firmware inconsistency.
18
Firmware mismatch error (ICU-Reus)
19
Boot error
20
Firmware & EEPROM conflict (MFP)
21
Firmware & EEPROM conflict (PCU)
22
Firmware & EEPROM conflict (SCU)
C1
Main Charge Trouble
10
Main charger trouble (black)
14
Main charger trouble (colour)
15
Main charger circuit trouble (black)
16
Main charger circuit trouble (colour)
40
MC PWB trouble
41
MC/TC PWB trouble
C4
PTC / 2TC Trouble
00
PTC trouble
05
PTC circuit trouble
20
Primary transfer output trouble
25
1TC circuit trouble
30
2
nd
transfer output open trouble
31
2
nd
transfer output short circuit
35
2TC circuit trouble
40
TC PWB trouble
CE
Network Communication Trouble
00
Network communication error
01
Network card is not installed or defective
02
FTP or Mail server is not found
03
Specified server does not correspond during
transmission
04
Invalid account/password (FTP server)
05
Invalid directory entered (FTP server)
06
Specified mail server (POP3) is not found
07
Invalid server account or password
08
The specified mail server (POP3) suspends
response
E6
SPF Shading Trouble
10
SPF shading error (Black level correction)
11
SPF shading error (White level correction)
14
SPF CCD-ASIC error
E7
MFP / HDD / LSU / PCU Control Trouble
01
MFP image data trouble.
03
HDD trouble.
04
HDD-ASIC error.
10
Shading trouble (Black level correction).
11
Shading trouble (White level correction).
14
CCD-ASIC communication error.
20
LSU laser detection error (K).
21
LSU laser detection error (C).
22
LSU laser detection error (M).
23
LSU laser detection error (Y).
24
LSU LD driver error (K)
25
LSU LD driver error (C)
26
LSU LD driver error (M)
27
LSU LD driver error (Y)
28
LSU-PCU connection trouble
29
LSU-ASIC frequency error
42
Image data trouble (ACRE-ASIC)
46
Image data decode error (ACRE-ASIC)
47
MFP & ACRE firmware inconsistency (ACRE-
ASIC)
48
Image data decode error (ACRE PWB)
49
Watermark data error
50
Firmware combination error (ICU – PCU)
55
PCU EEPROM sum check error
60
MFP combination error (Firmware/PWB)
61
MFP-PCU combination error
62
ICU connection error
80
MFP-SCU communication trouble.
90
MFP-PCU communication trouble.
91
Fax reception image data error
92
Copy image data error
93
Image data process error (except Copy &
Fax).
94
Image data process error (filing image data)
96
DIMM memory check error (MFP PWB)
99
LSU LD driver trouble
A0
LSU LD PWB EEPROM R/W error (K)
A1
LSU LD PWB EEPROM R/W error (C)
A2
LSU LD PWB EEPROM R/W error (M)
A3
LSU LD PWB EEPROM R/W error (Y)
A7
SSD trouble
EE
Developer Adjustment Trouble
EC
Auto DV adjustment trouble.
EL
Auto DV adjustment trouble (over toned).
EU
Auto DV adjustment trouble (under toned).
