Sharp MX-3070N

TEST SIMULATION
SHARP
58
66
Fax Control Settings & Adjustments
01
Fax Soft SW setting
SW24
Communication Signal sending level
(bits 1-8):
Default Value (Australia/NZ)
00001011
SW27-4
V.34 mode function (call arrival):
0 = V.34 valid.
1 = V.34 invalid.
SW27-5
V.34 mode function (polling when
calling):
0 = V.34 valid.
1 = V.34 invalid.
SW27-6
V.34 mode function (manual
communication):
0 = V.34 valid.
1 = V.34 invalid.
SW33-6,
SW33-7;
Transmission cable amplitude
equaliser:
00 = 0dB
01 = 4dB
10 = 8dB
11 = 12dB
02
Country code default set (Fax)
03
Fax PWB (modem) controller memory check
04
Fax signal line check (Max level)
05
Fax signal line check (Soft SW setting level)
06
Fax list print (confidential registration)
07
Fax image memory printout (all data)
08
Fax sound message setup
09
Fax signal line check (Soft SW setting)
10
Fax & Image data all memory clear
11
Voice signal check (line/speaker 300bps)
12
Voice signal check (line/speaker 300bps)
13
Register dial number for Sim 66-14/15/16
14
Adjust/check the time dial pulse (10bps)
15
Adjust/check the time dial pulse (20bps)
16
Adjust/check the send level DTFM signal
17
DTFM signal to send to line (Max level)
18
DTFM signal to send to line (Soft SW level)
21
Print various registration information
22
Set the sound volume of the handset (Japan)
29
Fax address book clear
30
Tel/LIU sensor status check
31
ON/OFF setting of output port (Tel/LIU)
32
Received data check (comparison)
33
Busy Tone/CNG/CED/FNET detect check
36
Check Send/Receive from modem.
39
Check Destination saved in Fax EEPROM
42
Rewrite PIC program installed on Fax box
66
Fax Control Settings & Adjustments
43
Write program & adjustment values to PIC
installed on Fax
61
Display FAX related soft switch (151-250)
62
FAX receive data export in PDF format.
67
Printer Settings & Adjustments
17
Printer NVRAM clear
24
Printer colour balance auto adjustment
25
Printer colour balance manual adjustment
26
Set the target colour balance for printer
mode auto colour adjustment
27
Set the target colour balance for printer
mode auto colour adjustment (Service)
28
Set the printer mode auto colour adjustment
back to factory default (Service)
31
Printer calibration data clear
33
Printer screen gamma adjust. (PCL/PS)
34
Printer maximum density adjustment mode
36
Adjust the density in printer low density
areas
41
2 colour print setup
42
2 colour print density setup
43
2 colour mode colour balance adjustment for
printer
52
Printer default gamma check (PCL/PS)
54
Printer colour balance adjustment
