Sharp MX-3070N

SHARP
TEST SIMULATION
53
ADJUSTMENT & SETTINGS (Cont’d)
DATA DISPLAY
Counter Display
22-01
DATA DISPLAY
List Printing
22-06
22-09
23-02
22-13
USB Storage
56-99
System / Version
22-05
HISTORY
History Date List
Use SIM
22-10
CLASSIC MODE – FULL SIMULATION LIST
1
Scanner Self-Test
01
Scanner operations test
02
Scanner sensor check
05
Scanner unit and control circuit check
2
Document Feeder Self-Test
01
SPF ageing test.
02
SPF sensor check
03
SPF output check (motor, clutch, solenoid)
3
Finisher Operation & Self-Test
02
Finisher sensor check
03
Finisher output / load check
10
Finisher adjustment
4
LCC Operation & Self-Test
02
LCC sensor check
03
LCC output / load check
05
DTRC & LTRC clutch operation check
5
Lamp Operation & Self-Test
01
LCD/LED operation panel test
02
Heater lamp load check
03
Scanner lamp control circuit check
04
Discharge lamp control circuit check
6
System Load Operation & Self-Test
01
Paper Feed output / load check
02
Fan control circuit check
03
Transport unit control circuit check
06
Fusing pressure release operation check
90
Reset machine to factory setting (scanner
mirror unit lock position execute).
7
MFP Aging Operation & Self-Test
01
Ageing test setting
06
Interval ageing cycle timer set up
08
Warm up time display setting
7
MFP Aging Operation & Self-Test
09
Colour setting in colour copy test mode.
12
Document reading setting (aging)
8
High Voltage Operation & Self-Test
01
Developer bias setting and output
02
MHV/Grid setting and output
06
Transfer setting and output
10
Main charger total current output setting
9
Duplex Operation & Self-Test
02
ADU sensor check
03
ADU load & output check
10
Toner Motor Operation & Self-Test
01
Toner motor operation check
03
Toner cartridge eject motor check
13
U1 Trouble Clear / Cancel
--
Trouble cancel (U1 trouble).
14
Trouble Clear / Cancel
--
Trouble cancel (excluding U1/U2/U6 trouble).
15
U6 Trouble Clear / Cancel
--
Trouble cancel (U6 trouble).
16
U2 Trouble Clear / Cancel
--
Trouble cancel (U2 trouble).
21
Maintenance Cycle Configuration
01
Maintenance cycle setting
22
MFP Data Output & Check
01
Counter data display
02
Jam/trouble counter display
03
Jam history data display
