MX-5001N SIMULATION 6 – 54
<Code descriptions>
<List of destination groups>
43-21
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the environment correction
under high temperature and high humidity
(H/H) for the fusing temperature setting
(SIM 43-1) in each paper mode.
Section
Operation/Procedure
1) Select an item to be set with [↑] [↓] keys.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value in step 2 is saved.
Correction value: -49 - +49, 1 Count = 1°C Change
[41-sheet machine]
TH_UM Fusing upper thermister main center HL_UM Heater lamp upper main
TH_LM Fusing lower thermister main HL_LM Heater lamp lower main
TH_E Fusing thermister external HL_E Heater lamp external
Group 1 Japan China AB_B
Group 2 U.S.A. Canada Inch
Group 3 Europe U.K. AUS AB_A
NOTE: When the destination is changed with SIM26-6 after changing this set value, the set values of the destination link items are reset to the default.
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
)86(57(03$'-8670(17//



$˖
˷˹
˖+/B805($'<//
$˖
˖+/B/05($'<//
%˖
˖+/B(5($'<//
&˖
˖+/B803/$,1%://
'˖
˖+/B(3/$,1%://
)˖
˖+/B/03/$,1%://
(˖
˖+/B803/$,1&///
*˖
˖+/B/03/$,1&///
+˖
˖+/B(3/$,1&///
,˖
˖:$5083)8021+/B(ǂ7ǂ//
-˖
˖:$5083)802))7ǂ//
.˖
˖:$5083(1'7,0(//
/˖
2.
Correction
value
-49 -25 -5 0 5 25 49
Input value 1 25 45 50 55 75 99
1
Item/Display Content
Setting
range
Default value Destination
linkage
(NOTE)
Group 1 Group 2 Group 3
A HL_UM READY HH Correction value for TH_UM set value in Ready standby
under HH environment
1 - 99 50 50 50 {
B HL_LM READY HH Correction value for TH_LM set value in Ready standby
under HH environment
1 - 99 50 50 50 {
C HL_E READY HH Correction value for TH_E set value in Ready standby
under HH environment
1 - 99 50 50 50 {
D HL_UM PLAIN BW HH Correction value for Black-White plain paper TH_UM set
value under HH environment
1 - 99 50 50 50 {
E HL_LM PLAIN BW HH Correction value for Black-White plain paper TH_LM set
value under HH environment
1 - 99 50 50 50 {
F HL_E PLAIN BW HH Correction value for Black-White plain paper TH_E set
value under HH environment
1 - 99 50 50 50 {
G HL_UM PLAIN CL HH Correction value for Color plain paper TH_UM set value
under HH environment
1 - 99 50 50 50 {
H HL_LM PLAIN CL HH Correction value for Color plain paper TH_LM set value
under HH environment
1 - 99 50 50 50 {
I HL_E PLAIN CL HH Correction value for Color plain paper TH_E set value
under HH environment
1 - 99 50 50 50 {
J WARMUP FUMON HL_E T HH Correction value for fusing motor pre-rotation start TH_E
set value under HH environment
1 - 99 50 50 50 –
K WARMUP FUMOFF T HH Fusing motor prior rotation completion time under HH
environment
1 - 99 50 50 50 –
L WARMUP END TIME HH Correction value for warm-up complete time under HH
environment
1 - 99 50 50 50 –
M HL_UM HEAVY HH Correction value for heavy paper TH_UM set value under
HH environment
1 - 99 50 50 50 –
: Oct. 24 2008
1
