MX-5001N SIMULATION 6 – 72
*1: When REFRESH MODE setting is enabled (0), the menu of the
user process control execution button is displayed on the user sys-
tem setting menu.
When the color balance or the density change is not within the
allowable range, the user can perform the process control manually
and forcibly. However, toner is consumed grater than as usual. This
point must be explained to the user clearly.
Process con-
trol Enable/
Disable set-
ting
F REV1 YES The accumulated traveling distance
of BK or M position OPC unit reaches
the specified level after turning the
power.
Enable 0 - 1 0 0
NO Inhibit 1
G REV2_BK YES The accumulated traveling distance
of BK position OPC drum unit
reaches the specified level from
execution of the previous density
correction.
Enable 0 - 1 0 0
NO Inhibit 1
H REV2_CL YES The accumulated traveling distance
of M position OPC drum unit reaches
the specified level from execution of
the previous density correction.
Enable 0 - 1 0 0
NO Inhibit 1
IREFRESH
MODE(*1)
YES Select of YES/NO of the manual
process control key with key
operation
Key operation
display
0 - 1 0 1
NO Key operation NO
display
1
Process control
conditions
setting
J DAY When the next warm-up if there is no
color job after a color job after
passing the specified days from
execution of the previous color
process control
Disable of the
specified days
judgment
0 - 999 0 1
1 - 999 days passing 1 -
999
K PIX_RATIO_BK Magnification ratio setting (%) of the BK toner count specified
value entry of 100 corresponds to 1k of A4 5% print.
1 - 999 10
L PIX_RATIO_CL Magnification ratio setting (%) of the color (CMY) toner count
specified value entry of 100 corresponds to 1k of A4 5% print.
1 - 999 10
M INTERVAL TIME Passing time setting of "TIME"(h: hour) 1-255
(1-255: 1-255h passed)
12
N HUM HOUR Interval setting of the temperature and humidity monitoring
time of "HUM" (h: hour)
1 - 24 2
O HUM_DIF Area difference specified value when compared with the
execution of the previous process control of "HUM”
1 - 9 2
P BK_RATIO Magnification ratio setting (%) of the specified value of the
BK position OPC drum traveling distance of "REV2_BK”
1-999
(Entry of 20 corresponds
to 100,000mm.)
15
Q M_RATIO Magnification ratio setting (%) of the M position OPC drum
traveling distance of "REV2_CL”
1-999
(Entry of 20 corresponds
to 100,000mm.)
15
R COLOR BORDER Magnification ratio setting (%) of the
M position OPC drum traveling
distance when executing the BK
process control
BK process control
is executed without
judgment of ratio of
the M OPC drum
traveling distance.
0 - 999 0 20
1 - 999(%) 1 -
999
S BK ONLY Disable/Enable setting and setting of
the number of repetition of the BK
process control when monochrome
print is continued.
Enable 5 time 0 - 6 0 5
Disable 1-5 times 1 - 5
Inhibit 6
T HT_DIF Bias change difference value used for judgment of HT
process control
1 - 255 40
Registration
adjustment
setting
U RG_ON_SYNC CL Select of synchronous/asynchronous of the power ON
process control
0 - 2 0 0
ALL 1
CL/BK 2
V RG_TEMP_TIMER Execution timing setting after turning ON the power 0 - 240 (MINUTE) 60
W RG_PERM_TIMER Span setting from execution Disable to Enable 0 - 15 (HOUR) 1
X RG_HOUR_TIMER Span setting of timer execution 0-15 (Above)+(HOUR) 5
Secondary
transfer
cleaning setting
Y 2TRAN_CLEAN_TIME1 Secondary transfer cleaning process time judgment
threshold value 1
1 - 999 200
Z 2TRAN_CLEAN_TIME2 Secondary transfer cleaning process time judgment
threshold value 2
1 - 999 300
AA 2TRAN_CLEAN_TIME3 Secondary transfer cleaning process time judgment
threshold value 3
1 - 999 500
Mode Item/Display Content Setting range
Default
value
