MX-5001N SIMULATION 6 – 75
<Use example>
(*1)
Make multi copy of 10 sheets. If the density of 10th sheet is greater than that of the first sheet, decrease the set value.
Make multi copy of 10 sheets. If the density of 10th sheet is smaller than that of the first sheet, increase the set value.
When the set value is 0 (Default), the correction level does not work.
44-43
Purpose
Data display
Function (Purpose)
Used to display the identification informa-
tion of the developing unit.
Section
Developing system
Operation/Procedure
The identification number and the identification signal level of the
developing unit are displayed.
Item/Display Default value
Black CMY Black CMY Variable range
Current DV Bias
voltage
Low speed mode
Heavy paper mode
less than 300[v] A A 0 0 0-5
(*1)
300[v] or more, less than 450[v] B B 0 0
450[v] or more C C 0 0
Middle speed mode less than 300[v] D D 0 0
300[v] or more, less than 450[v] E E 0 0
450[v] or more F F 0 0
High speed mode
Monochrome mode
less than 300[v] G - 0 -
300[v] or more, less than 450[v] H - 0 -
450[v] or more I - 0 -
Time (T) from
termination of
continuous outputs
to start of the next
output operation
Low speed mode
Heavy paper mode
Less than 10 [sec] & after process control JOB J G 4 4 1-12
10 [sec] or more, less than 60 [sec] K H 3 3
60 [sec] or more, less than 240 [sec] L I 1 1
240 [sec] or more M J 1 1
Middle speed mode Less than 10 [sec] & after process control JOB N K 4 4
10 [sec] or more, less than 60 [sec] O L 3 3
60 [sec] or more, less than 240 [sec] P M 1 1
240 [sec] or more Q N 1 1
High speed mode
Monochrome mode
Less than 10 [sec] & after process control JOB R - 4 4
10 [sec] or more, less than 60 [sec] S - 3 3
60 [sec] or more, less than 240 [sec] T - 1 1
240 [sec] or more U - 1 1
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
,0$*('(16,7<'9%$'-8670(176(77,1*



$˖
˷˹
˹
˖'9B$'-B&/B.B/B'$7$B
$˖
˖'9B$'-B&/B.B/B'$7$B
%˖
˖'9B$'-B&/B.B/B'$7$B
&˖
˖'9B$'-B&/B.B0B'$7$B
'˖
˖'9B$'-B&/B.B0B'$7$B
)˖
˖'9B$'-B&/B.B0B'$7$B
(˖
˖'9B$'-B%.B+B'$7$B
*˖
˖'9B$'-B%.B+B'$7$B
+˖
˖'9B$'-B%.B+B'$7$B
,˖
˖'9B$'-B67$57B&/B.B/B
-˖
˖'9B$'-B67$57B&/B.B/B
.˖
˖'9B$'-B67$57B&/B.B/B
/˖
2.. & 0 <
Item/Display Content Display
range
A DVCH KIND K K color development unit
identification number
1 - 9
B DVCH KIND C C color development unit
identification number
1 - 9
C DVCH KIND M M color development unit
identification number
1 - 9
D DVCH KIND Y Y color development unit
identification number
1 - 9
E DVCH_AD_K K color developing unit identification
number AD value
0 - 255
F DVCH_AD_C C color developing unit identification
number AD value
0 - 255
G DVCH_AD_M M color developing unit
identification number AD value
0 - 255
H DVCH_AD_Y Y color developing unit identification
number AD value
0 - 255
Item/Display Content Display
range
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
'(9(/23(581,7$'021,725



'9&+.,1'.
'9&+.,1'&
'9&+.,1'0
'9&+.,1'<
'9&+B$'B.
'9&+B$'B&
'9&+B$'B0
'9&+B$'B<
