MX-5001N SIMULATION 6 – 83
46-32
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the document background
density reproducibility in the monochrome
auto copy mode.
Section
Operation/Procedure
1) Select a target item of setting with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
When the adjustment value is increased, reproducibility of the
background and the low density image is increased. When the
adjustment value is decreased, reproducibility of the background
and the low density image is decreased.
[RSPF]
[DSPF]
46-36
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the colors in the 2-color
copy mode.
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key. (The set value is saved.)
By changing the density level of each color, the color adjustment in
the 2-color copy mode can be performed.
46-37
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the color document repro-
ducibility in the monochrome copy mode.
Section
Operation/Procedure
1) Select a target item with [↑] [↓] keys on the touch panel.
2) Enter the set value with 10-key.
3) Press [EXECUTE] key.
4) Press [YES] key.
This simulation is used to adjust the reproducibility of red and yel-
low images when copy a color document of red and yellow images
in the monochrome mode.
* B-Ratio: The value of gray making setting (B) is obtained from
the formula below.
1000-R-Ratio - G-Ratio
Item/Display Content
Setting
range
Default
value
A COPY : OC Copy mode (for OC) 1 - 250 196
B COPY : RSPF Copy mode (for RSPF) 1 - 250 196
C SCAN : OC Scanner mode (for OC) 1 - 250 196
D SCAN : RSPF Scanner mode
(for RSPF)
1 - 250 196
E FAX : OC FAX mode (for OC) 1 - 250 196
F FAX : RSPF FAX mode (for RSPF) 1 - 250 196
Item Display Content
Setting
range
Default
value
A COPY: OC Copy mode (for OC) 1 - 250 196
B COPY: DSPF
(SIDE1)
Copy mode (for DSPF) 1 - 250 196
C COPY: DSPF
(SIDE2)
Copy mode (for DSPF) 1 - 250 196
D SCAN: OC Scanner mode (for OC) 1 - 250 196
E SCAN: DSPF
(SIDE1)
Scanner mode (for DSPF) 1 - 250 196
F SCAN: DSPF
(SIDE2)
Scanner mode (for DSPF) 1 - 250 196
G FAX: OC FAX mode (for OC) 1 - 250 196
H FAX: DSPF
(SIDE1)
FAX mode
(for DSPF front surface)
1 - 250 196
I FAX: DSPF
(SIDE2)
FAX mode
(for DSPF back surface)
1 - 250 196
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
/,0,72)$(5($&7,216(77,1*



$˖
˷˹
˖&23<˖2&
$˖
˖&23<˖'63)˄6,'(
%˖
˖&23<˖'63)˄6,'(
&˖
˖6&$1˖2&
'˖
˖6&$1˖'63)˄6,'(
)˖
˖6&$1˖'63)˄6,'(
(˖
˖)$;˖2&
*˖
˖)$;˖'63)˄6,'(
+˖
˖)$;˖'63)˄6,'(
,˖
2.
Item/Display Content
Setting
range
Default value
CMY
A RED R output color 0 - 255 0 255 200
B GREEN G output color 0 - 255 255 0 255
C BLUE B output color 0 - 255 255 200 0
D CYAN C output color 0 - 255 255 0 0
E MAGENTA M output color 0 - 255 0 255 0
F YELLOW Y output color 0 - 255 0 0 255
Item/Display Content
Setting
range
Default
value
A R-Ratio Gray making setting (R) 0 - 1000 172
B G-Ratio Gray making setting (G) 0 - 1000 828
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
5('%/$&.&2/25&23<$'-8670(17



$˖
˷˹
˖5('
$˖
˖*5((1
%˖
˖%/8(
&˖
˖&<$1
㪛˖
˖<(//2:
㪝˖
˖0$*(17$
㪜˖
2.
& 0 <
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
%:,0$*(&5($7($'-8670(17%5DWLR



$˖
˷  ˹
˖55DWLR
$˖
˖*5DWLR
%˖
'()$8/7
$5(<28685("
<(6 12 (;(&87(
