MX-5001N SIMULATION 6 – 89
46-51
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the gamma for the copy
mode heavy paper mode and the image
process mode.
Section
Operation/Procedure
1) Select a target adjustment mode with the touch panel key
[PAPER/DITHER].
2) Select an adjustment target color with [K][C][M][Y] keys on the
touch panel.
3) Select a target adjustment density level with [↑] [↓] key on the
touch panel.
4) Enter the set value with 10-key.
5) Press [EXECUTE] key, or [OK] key.
When [EXECUTE] key is pressed, the self print image is out-
putted.
When the image density is insufficient or a background copy is
made in heavy paper copy, change this adjustment value to adjust
the image density.
46-52
Purpose
Adjustment/Setup
Function (Purpose)
Used to set the gamma default for the copy
mode heavy paper and the image process
mode. (The set values of SIM46-51 are set
to the default values.)
Section
Operation/Procedure
1) Select an item to be set to the default with the touch panel key.
To reset the adjustment values of all the items, select [ALL].
2) Press [EXECUTE] key.
3) Press [YES] key.
4) Press [EXECUTE] key.
46-54
Purpose
Adjustment
Function (Purpose)
Used to perform the engine half tone auto-
matic density adjustment (dither).
Section
Operation/Procedure
1) Press [EXECUTE] key.
The high density process control is started to make 32 patch
self print. (A3 paper in the paper feed tray is used.)
2) Place the 32 patch self print on the document table, and press
[EXECUTE] key.
Scanning the 32 patch self print is started.
After scanning the 32 patch self print, the 16 patch self print is
automatically printed.
3) Press [OK] key.
After completion of the correction amount registration, the
screen shifts to the dither selection menu.
4) Select an item (dither) to be adjusted.
5) Press [EXECUTE] key.
The 32 patch self print is printed.
6) Place the 32 patch self print on the document table, and press
[EXECUTE] key.
Scanning the 32 patch self print is started.
After scanning the patch, the screen automatically shifts to the
dither selection menu.
Item/Display Content Color
HEAVY Copier heavy paper gamma KCMY
DITH1 Black edge K
DITH2 Color edge KCMY
DITH3 Color error diffusion KCMY
DITH4 Monochrome error diffusion K
Item/Display
Density level
(Point)
Setting range
Default
value
A POINT1 Point 1 245 - 755 500
B POINT2 Point 2 245 - 755 500
C POINT3 Point 3 245 - 755 500
D POINT4 Point 4 245 - 755 500
E POINT5 Point 5 245 - 755 500
F POINT6 Point 6 245 - 755 500
G POINT7 Point 7 245 - 755 500
H POINT8 Point 8 245 - 755 500
I POINT9 Point 9 245 - 755 500
J POINT10 Point 10 245 - 755 500
K POINT11 Point 11 245 - 755 500
L POINT12 Point 12 245 - 755 500
M POINT13 Point 13 245 - 755 500
N POINT14 Point 14 245 - 755 500
O POINT15 Point 15 245 - 755 500
P POINT16 Point 16 245 - 755 500
Q POINT17 Point 17 245 - 755 500
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
&23,(5+($9<3$3(5*$00$$'-8670(17+($9<



$˖
˷˹
˖32,17
$˖
˖32,17
%˖
˖32,17
&˖
˖32,17
'˖
˖32,17
)˖
˖32,17
(˖
˖32,17
*˖
˖32,17
+˖
˖32,17
,˖
˖32,17
-˖
˖32,17
.˖
˖32,17
/˖
2.. & 0 <
(;(&87(3$3(5',7+(5
HEAVYPAPER Copier/gamma for heavy paper
BLACK EDGE Black edge
COLOR EDGE Color edge
COLOR ED Color error diffusion
B/W Monochrome error diffusion
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
&23<&$/,%5$7,21'$7$&/($5$7',7+(5


+($9<3$3(5 %/$&.('*( &2/25('&2/25('*(
%:
$//
$5(<28685("
<(6 12 (;(&87(



