MX-5001N SIMULATION 6 – 92
46-63
Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the density in the copy low
density section.
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the adjustment value using the 10-key.
3) Press [OK] key.
When the adjustment value is increased, reproducibility of the
background and the low density image is increased. When the
adjustment value is decreased, reproducibility of the background
and the low density image is decreased.
46-74
Purpose
Adjustment
Function (Purpose)
Copy color balance adjustment (Auto
adjustment)/Printer color balance adjust-
ment (Auto adjustment)
Section
Operation/Procedure
This simulation is used to perform SIM46-24 and SIM67-24 contin-
uously.
To perform both the copy color balance adjustment (Automatic
adjustment) and the printer color balance adjustment (Automatic
adjustment), use this simulation for efficient adjustment operations.
1) Press [EXECUTE] key, and the high density process control is
performed. Then, the copy color balance adjustment pattern is
printed.
2) Plate the printed adjustment pattern on the document table,
select [FACTORY] or [SERVICE] mode.
3) Press [EXECUTE] key, and the copy color balance adjustment
is performed and the adjustment result pattern is printed.
4) Press [EXECUTE] key, and the printer color balance adjust-
ment pattern is printed.
5) Plate the printed adjustment pattern on the document table,
select [FACTORY] or [SERVICE] mode.
6) Press [EXECUTE] key, and the printer color balance adjust-
ment (automatic adjustment) is performed and the adjustment
result pattern is printed.
7) Press [OK] key, and the half tone correction target is regis-
tered.
NOTE: The adjustment result becomes effective only when the
adjustment operations in the both modes are completed all
the way. For example, when the copy color balance adjust-
ment (automatic adjustment) is performed and the simula-
tion is canceled, the adjustment result is not effective.
S MODE0_UNDER Mode 0 photography
mode select threshold
value
0 - 6 0
T MODE1_UNDER Mode 1 photography
mode select threshold
value
0 - 6 0
U MODE5_UNDER Mode 5 photography
mode select threshold
value
0 - 6 0
V MODE6_UNDER Mode 6 photography
mode select threshold
value
0 - 6 0
Item/Display Content
Setting
range
Default
value
A COLOR COPY :
TEXT/PRINTED
Text print
(color copy)
1 - 9 3
B COLOR COPY :
TEXT
Text
(color copy)
1 - 9 3
C COLOR COPY :
PRINTED PHOTO
Printed photo
(color copy)
1 - 9 5
D COLOR COPY :
PHOTOGRAPH
Photograph
(color copy)
1 - 9 5
E COLOR COPY :
TEXT/PHOTO
Text/Photograph
(color copy)
1 - 9 3
F COLOR COPY :
MAP
Map
(color copy)
1 - 9 5
G COLOR COPY :
LIGHT
Light document
(color density)
1 - 9 6
H COLOR COPY :
TEXT/PRINTED
(COPY TO COPY)
Copy document,
Character print
(color copy)
1 - 9 5
I COLOR COPY :
TEXT
(COPY TO COPY)
Copy document,
Character
(color copy)
1 - 9 5
J COLOR COPY :
PRINTED PHOTO
(COPY TO COPY)
Copy document,
Printed photo
(color copy)
1 - 9 5
Item/Display Content
Setting
range
Default
value
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
09,(:-8'*(0(17/(9(/$'-8670(17



$˖
˷ ˹
˖6:B$&6
$˖
˖7(;7B,0$*(
%˖
˖7(;7B%/$1.
&˖
˖+7B/9
'˖ǂ
˖$(B/9B&&
)˖
˖$(B$5($B/9
(˖
˖$(B/9B0&
*˖
˖$(B/9B&6
+˖
˖$(B/9B06
,˖
˖$(B-8'*(B/9B/B8
-˖
˖$(B-8'*(B/9B/B2
.˖
˖$(B-8'*(B/9B&
/˖
2.
K COLOR PUSH :
TEXT/PRINTED
Text print
(color PUSH)
1 - 9 3
L COLOR PUSH :
TEXT
Text
(color PUSH)
1 - 9 3
M COLOR PUSH :
PRINTED PHOTO
Printed photo
(color PUSH)
1 - 9 5
N COLOR PUSH :
PHOTOGRAPH
Photograph
(color PUSH)
1 - 9 5
O COLOR PUSH :
TEXT/PHOTO
Text/Photograph
(color PUSH)
1 - 9 3
P COLOR PUSH :
MAP
Map
color PUSH)
1 - 9 5
Item/Display Content
Setting
range
Default
value
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
%*5(029($'-8670(17



$˖
˷
˹
˖&2/25&23<7(;7
35,17('3+272
$˖

˖&2/25&23<
7(;7
%˖

˖&2/25&23<
35,17('3+272
&˖

˖&2/25&23<
3+272*5$3+
'˖

˖&2/25&23<
0$3
)˖

˖&2/25&23<
7(;73+272
(˖

˖&2/25&23<
/,*+7
*˖

˖&2/25&23<7(;735,17('3+272
&23<72&23<
+˖

˖&2/25&23<7(;7
&23<72&23<
,˖

˖&2/25&23<35,17('3+272
&23<72&23<
-˖

˖&2/25386+7(;7
35,17('3+272
.˖

˖&2/25386+
7(;7
/˖

2.
