Purpose
Adjustment/Setup
Function (Purpose)
Used to adjust the high compression PDF
ASIC.
(Do not change default value in the field)
Section
Operation/Procedure
1) Select a target adjustment mode with [TEXT], [COLOR] and
[BG LAYER] keys.
2) Select a target adjustment item with [↑] [↓] key.
3) Enter the set value with 10-key.
4) Press [OK] key.
The set value is saved.
48
48-1
Purpose
Adjustment
Function (Purpose)
Used to adjust the scan image magnifica-
tion ratio (in the main scanning direction
and the sub scanning direction).
Section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value is saved.
When the adjustment value is increased, the image magnification
ratio is increased.
A change of "1" in the adjustment value of item A, C, or E corre-
sponds to a change of about 0.02% in the copy magnification ratio.
A change of "1" in the adjustment value of item B, D, or F corre-
sponds to a change of about 0.1% in the copy magnification ratio.
[RSPF]
[DSPF]
Item Button Display Content
Setting
range
Default
value
A TEXT GLYPH
SENSITIVITY
Text handling
selection
0 - 2 0
B BG SW FOR
FINDLINES
Line handling
selection
0 - 1 0
CHOR
FINDLINES SW
Line detection
SW (H)
0 - 2 0
D VERT
FINDLINES SW
Line detection
SW (V)
0 - 2 0
E FGCOLOR
INDEXING SEL
Te x t c o lor
number
adjustment SW
0 - 3 0
F FGCOLOR
INDEXING ADJ
Te x t c o lor
adjustment
0 - 4 2
A COLOR LUMINANCE
ADJUSTMENT
Luminance
adjustment
0 - 4 2
B CHROMA
INTENT
Chroma
selection
0 - 2 1
ABG
LAYER
BG LAYER
INTENT 1
Speed priority
setting
0 - 2 1
B BG LAYER
INTENT 2
Image quality
priority setting
0 - 2 1
