MX-5001N SIMULATION 6 – 94
48-5
Purpose
Adjustment
Function (Purpose)
Used to correction the scan image magnifi-
cation ratio (in the sub scanning direction).
Section
Scanner section
Operation/Procedure
1) Select a target adjustment item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
3) Press [OK] key.
The set value is saved.
When the image magnification ratio in the sub scanning direction is
adjusted with SIM48-1, and a different magnification ratio is speci-
fied, and the image magnification ratio is not satisfactory, perform
this adjustment.
When there is an error in the image magnification ratio in reduction,
change the adjustment value in the high speed mode. When there
is an error in the image magnification ratio in enlargement, change
the adjustment value in the low speed mode.
48-6
Purpose
Adjustment
Function (Purpose)
Used to adjust the rotation speed of each
motor.
Section
Operation/Procedure
1) Select an adjustment target mode with [COLOR] [MONO]
[HEAVY] keys on the touch panel.
2) Select a target adjustment item with [↑] [↓] key on the touch
panel.
3) Enter the set value with 10-key.
4) Press [OK] key.
The set value is saved.
When the adjustment value is increased, the speed is increased,
and vice versa. A change of 1 in the adjustment value corresponds
to a change of about 0.1% in the speed.
Item/Display Content
Setting
range
Default
value
A MR (HI) Scanner motor (High speed) 1 - 99 50
B MR(MID) Scanner motor
(Reference speed)
1 - 99 50
C MR(LO) Scanner motor (Low speed) 1 - 99 50
D SPF(HI) Document feed (SPF) motor
(High speed)
1 - 99 50
E SPF(MID) Document feed (SPF) motor
(Reference speed)
1 - 99 50
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
0$*1,),&$7,21$'-8670(17



$˖
˷
˹
˖&&'
0$,1
$˖

˖&&'
68%
%˖

˖63)
0$,1
&˖

˖63)
68%
'˖

˖63)%
0$,1
(˖

2.
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
0272563(('$'-8670(17



$˖
˷
˹
˖05
+,
$˖

˖05
0,'
%˖

˖05
/2
&˖

˖63)
+,
'˖

˖63)
0,'
(˖

2.
Mode
Select
Item/Display Content
Setting
range
Default value
41-sheet
machine
50-sheet
machine
COLOR A RRM Resist
motor
correction
value
1 - 99 50
49
B BTM Belt motor
correction
value
1 - 99 45
45
C DM_K Drum K
motor
correction
value
1 - 99 43
43
D DM_CL Drum CL
motor
correction
value
1 - 99 43
43
E DVM_K Developing
K motor
correction
value
1 - 99 50
50
F FSM Fusing
motor
correction
value
1 - 99 20
14
G DVM_CL Developing
CL motor
correction
value
1 - 99 50
50
H PFM Paper
transport
motor
correction
value
1 - 99 50
50
I POM Paper exit
motor
correction
value
1 - 99 45
45
MONO A RRM Resist
motor
correction
value
1 - 99 50
49
B BTM Belt motor
correction
value
1 - 99 45
45
C DM_K Drum K
motor
correction
value
1 - 99 43
43
D DVM_K Developing
K motor
correction
value
1 - 99 50
50
E FSM Fusing
motor
correction
value
1 - 99 20
14
1
: Oct. 24 2008
1
