MX-5001N SIMULATION 6 – 96
49-3
Purpose
Function (Purpose) Used to update the operation manual in the
HDD.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
* When the USB is not inserted, "INSERT A STORANGE E-
MANUAL STORED ON" is displayed. When [OK] key is
pressed, the display is shifted to the folder select menu 1.
2) Press the folder button of the operation manual data. (The dis-
play is shifted to the operation manual update menu.)
The current version and the update version are displayed.
3) Press [EXECUTE] key.
[EXECUTE] key is highlighted, and [YES] [NO] keys becomes
active from gray out.
4) When [YES] key is pressed, the selected operation manual is
updated.
When update is completed normally, "COMPLETE" is dis-
played. When terminated abnormally, "ERROR" is displayed.
(Folder select display 1)
49-5
Purpose
Function (Purpose) Used to perform the watermark update.
Section
Operation/Procedure
1) Insert the USB memory into the main unit.
2) Select the button of the folder to perform the watermark
update.
3) The current version and the update version are displayed.
4) Press [EXECUTE] key.
5) Press [YES] key.
The selected watermark is updated.
50
50-1
Purpose
Adjustment
Function (Purpose)
Copy image position, image loss adjust-
ment
Section
Operation/Procedure
1) Select an adjustment target item with [↑] [↓] key on the touch
panel.
2) Enter the set value with 10-key.
Set the items other than RRCA, LEAD, and SIDE to the
default.
RRCA: Image lead edge reference position adjustment
LEAD: Lead edge image loss adjustment
SIDE: Side image loss adjustment
3) Press [OK] key. (The set value is saved.)
FINM Inner finisher MAIN section
FIN1B 1K finisher Boot section
FIN1M 1K finisher Main section
FIN4B 4K finisher Boot section
FIN4M 4K finisher Main section
1PUNB Punch unit Boot section for 1K finisher
1PUNM Punch unit Main section for 1K finisher
4PUNB Punch unit Boot section for 4K finisher
4PUNM Punch unit Main section for 4K finisher
SCUB SCU Boot section
SCUM SCU Main section
DSPFB DSPF Boot section
DSPFM DSPF Main section
FAXB FAX1 Boot section
FAXM FAX1 Main section
FXOPB FAX2 Boot section (Japan only)
FXOPM FAX2 Main section (Japan only)
ESCP ESC/P font
PDL PDL font
ANIME Animation data
IMGDT Image ASIC data
CORP Color profile
WEBHP WEB help
UNICD UNICODE table
ACREB ACRE Boot section
ACREM ACRE Main section
ACRED ACRE table
Item/Display Content
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
),50:$5(83'$7(>XVEEG@
',5!)2/'(5 ),/(
),/( ',5!)2/'(5
ǂǂǂ6,08/$7,21ǂǂ12
&/26(
7(67
(0$18$/83'$7(>XVEEG@
',5!)2/'(5 ),/(
),/( ',5!)2/'(5
',5!0$18$/
ǂǂǂ6,08/$7,21
ǂǂ12
&/26(
7(67
:$7(50$5.83'$7(>XVEEG@
',5!)2/'(5 ),/(
),/( ',5!)2/'(5
',5!:0
